Flying Shear for Roll Forming machines – Instruction manual Pag. 16 / 29
Command mapping word
The word sent by the PLC containing the commands is written in the Dig word decomp parameter (PAR
4450). The different function commands are linked to the word bits by selecting the appropriate “bitxx decomp
mon”.
WORD
DECOMP
BIT NUMBER
WORD DECOMP
[HEX]
DESCRIPTION
0
0x0001
Enable
1
0x0002
Fast Stop
2
0x0004
Jog -
3
0x0008
Jog +
4
0x0010
Auto
5
0x0020
Homing
6
0x0040
Home sens
7
0x0080
Imm cut
8
0x0100
Blade close
9
0x0200
Blade open
10
0x0400
Virtual line
11
0x0800
Virtual blade
12
0x1000
Reset pos mat
13
0x2000
Not used
14
0x4000
Not used
15
0x8000
Not used
Table 5: Command mapping word
