INSPECTION AND MAINTENANCE
Inspection and maintenance interval
................................Every 250 hours
Cleaning the Condenser
IMPORTANT: Cleaning the condenser
with high pressured water may damage
it. Clean the condenser gently.
If the condenser is dirty, heat will not discharge
properly. Wash dirt off the condenser with
water.
1. Open the rear door.
2. Clean the condenser (1).
Inspecting and Adjusting the Air
Conditioner Belt
IMPORTANT: Do not let any oil or grease
get on the belt, because it will cause the
belt to slip, shortening its service life and
reducing the air conditioner’s cooling
capacity.
If the belt is slack, it will slip and vibrate,
shortening its service life and reducing the
air conditioner’s cooling capacity. The belt
should also not be too tight. Adjust the belt
tension to the standard value (approximately
8 mm or 0.3 in.).
Inspection
1. Open the radiator door.
2. Press on the center of the belt (1) with
a finger. The belt’s tension is normal
if it deflects about 8 mm (0.3 in.) when
pressed with a force of about 98 N (22
lbs.).
Adjustment
If the belt’s tension is not normal, adjust it
with the adjust bolt (3).
1. Loosen the nut (4).
2. Tighten the bolt (3) to decrease the
tension.
Loosen the bolt (3) to increase the
tension.
3. After adjusting is completed, tighten the
nut (4).
