Machine Operation
Operating the Left Control Lever
WARNING
Never allow anyone to enter the turning
radius and machine path.
Signal your intention to move by
sounding the horn.
Traveling and turning should be
performed with the bucket cylinder fully
retracted and the bucket at a height of
approximately 30 cm (12 in.) from the
ground.
Avoid sudden stops, start or turns.
Do not raise the safety bar while
traveling. This is dangerous, because
raising the safety bar will cause the
parking brakes of the travel motors to
operate and apply the brakes abruptly.
Do not switch off the ignition switch
while traveling. Doing so will cause
sudden braking and is dangerous.
Before backing up, visually check for
safety to the rear. Backing up without
checking could result in contact with a
worker or obstacle.
If unavoidable while traveling, when
operating the working equipment, do
so with care.
Avoid crossing over obstacles whenever
possible. If you must do so, keep the
bucket close to the ground and travel
slowly. Never cross obstacles if they
will seriously tilt the machine (to an
angle of 15° or greater).
When traveling on rough terrain or
when carrying a load, lower the load
and travel slowly.
Remove any obstacles in the machine’s
path.
Use the left control lever to operate the
crawler tracks.
Return the left control lever to the neutral
position to stop the tracks.
1. Increase the engine speed.
2. Set the safety bar to the released
position.
3. Roll back the bucket fully and lift the bucket
to 30 cm (12 in.) above the ground.
