WARNING
Tilt, lift, and extend cylinders have counter-
balance valves. These valves keep hydraulic
fluid from entering and exiting the cylinders
while they are not being activated, and they
are under extremely high pressure. Before
removing one of these valves, you ARE
REQUIRED to call your Gehl dealer or Gehl
Service Department. Failure to do so may
result in serious injury or death.
ELECTRICAL COMPONENTS
An electrical system schematic is provided, which
includes instrumentation, electrical components and
switch connections. It is located at the back of this
manual and can be used as a guide for service refer-
ence, as required.
OPERATOR SERVICES
Some of the operator-related services will require
access to components located inside the superstructure,
under shields, hoods and covers. The chart on this page
notes the components accessed in each particular area.
Component Operator’s Frame Front Frame Front Engine Rear Engine
Station Cover Cover Cover
Axle (underside) l
Engine l
Hydrostatic Transmission ll
Drive Shaft (underside) l
Main Control Valve (center) l
Muffler (rear) l
Air Cleaner (front) l
Battery (front) l
Radiator l
Brake Valve (center) l
Travel Controls (steer column) l
Boom Controls (right inside) l
Hydraulic Test Ports l
Hourmeter (dash) l
Switches/Indicators (dash) l
Hydraulic Pump (front) l
Hydraulic Filter l
Misc. Hydraulic Valves ll
Heater (lower dash area) l
Fuse and Relay Panel l
ACCESS TO COMPONENTS CHART
