PRINTED IN U.S.A. 3 50960066/AP0813
Identification
Telescopic Boom
Operator’s Station
Quick-attach
System
Tilt Cylinder
Slave Cylinder
Dash Indicators
and Controls
Seat
Fuel Tank
Behind Access
Cover
Rear Boom
Access Cover
Lift Cylinder
Hydraulic Tank
Filler under
Engine Cover
Extend Cylinder
Inside Boom
Air Cleaner
under Engine
Cover
Exhaust Pipe
Auxilluary
Hydraulics
Rear View
Mirror

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gehl RS5-19 and is the answer not in the manual?

Gehl RS5-19 Specifications

General IconGeneral
Fuel TypeDiesel
Tire TypePneumatic
Maximum Lift Height19 ft
EngineDeutz TD 2.9L Tier 4 Final
Steering4-Wheel
Lift Height19 ft
