Gehl RS5-19 User Manual

50960066/AP0813 64 PRINTED IN U.S.A.
REF. DESCRIPTION PART NO.
NO.
01 WARNING-TILT HAZARD/GENERAL OPERATOR L70306
02 WARNING - CARRY LOAD LOW L65926
03 F-N-R SHIFT L68295
04 MADE IN USA 140516
05 WARNING - PARK BRAKE/SEAT BELT 101506
06 DANGER-HI VOLT./MOVING PARTS L70307
07 STANDARD CARRIAGE LOAD CHART 104399
ROTATING CARRIAGE LOAD CHART 104400
BUCKET LOAD CHART 104401
TRUSS BOOM LOAD CHART 104402
FORK SHIFT LOAD CHART 105804
SIDE SHIFT LOAD CHART 210011
08 ATTACHMENT TILT/AUXILIARY 100400
09 BOOM CONTROL L63631
10 IGNITION/START/HORN 50380266
11 DANGER-PERSONNEL INJURY L65928
12 OPERATOR MANUAL WARNING 100359
13 LUBE CHART 50380364
14 NO RIDERS L65932
15 WARNING - PINCH POINT L65927
16 TIE DOWN 104945
17 LIFT POINT 104946
DECAL LOCATIONS
4
3
13
11
12
14
10
1
5
6
2
8
9
7
16
16
15
17
16
17

Gehl RS5-19 Specifications

General

Fuel Type	Diesel
Tire Type	Pneumatic
Maximum Lift Height	19 ft
Engine	Deutz TD 2.9L Tier 4 Final
Steering	4-Wheel
Lift Height	19 ft
