8 - TECHNICAL FEATURES
H
L
Z
H
L
Ø
Controls the system by setting the time interval
in 4 days between two regenerations.
The ET AD version is fitted with a self-
disinfection system.
ET ELECTRONIC TIMER
Allows a higher flexibility thanks to the volume/
time programming, with automatic adjustment
to actual consumptions and automatic
regeneration after 4 days.
The ET AD version is fitted with a
self-disinfection system.
VT ELECTRONIC TIMER
HYDROTECHNOLOGY
HYDROTECHNOLOGY
Model
Cyclic
∆ P
Flow rate potable use Flow rate technical use Salt tank Salt consum. Regen.
Connections
Dimensions
(l)
capacity
(bar)
operation peak operation peak capacity per regen. duration
(”)
L x H x Z
(m
3
x1°f) (l/h) (l/min)* (l/h) (l/min)* (l) (Kg) (minuti) (cm)
5 30 <0,5 300 8 50 1 35 0,75 28 1 1/4” 38x53x48
8 48 <0,5 480 13 80 1 70 1,20 32 1 1/4” 31x62x46
15 90 <0,5 900 24 150 3 135 2,25 37 1 1/4” 33x111x47
20 120 <0,5 1200 32 200 4 125 3,00 39 1 1/4” 33x111x47
25 150 <0,5 1500 40 250 5 120 3,75 40 1 1/4” 33x111x47
DECALUX BASIC
Model
Cyclic
∆ P
Flow rate potable use Flow rate technical use Salt tank Salt consum. Regen.
Connections
Dimensions
(l)
capacity
(bar)
operation peak operation peak capacity per regen. duration
(”)
L x H x Z
(m
3
x1°f) (l/h) (l/min)* (l/h) (l/min)* (l) (Kg) (minuti) (cm)
15 90 <0,5 900 24 150 3 100 2,25 37 1 1/4” 24x111x47
20 120 <0,5 1200 32 200 4 100 3,00 39 1 1/4” 24x111x47
25 150 <0,5 1500 40 250 5 100 3,75 40 1 14” 25x111x47
DECAL BASIC
ACCESSORIES
Manual by-pass* (hardness mixing valve)
- Connections: 1
1
/
2
” M
- Adaptors included in the supply: 1
1
/
2
”F - 1”M
* The mixing valves is necessary for adjusting the
residual water hardness.
