Gemini 15 User Manual

Gemini series User Manual
1.4
Product Specification
1.4.1
Gemini 15
Specification
Model name
Gemini 15
Number of ports
1
Dimension
459.6 x 448.3 x 44 mm / 18.1 x 17.6 x 1.7 inches
Package Dimension
606 x 551.5 x 230 mm / 23.9 x 21.7 x 9.0 inches
Net Weight
12 Kg / 26.5 lbs
Gross Weight
19.5 Kg / 43.0 lbs
Display Size
15 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1024 x 768 (XGA)
Pixel Pitch
Supports 0.297 mm x 0.297 mm
Viewing Angle (CR>10)
Right-Left view 130°(Typ)
Up-Down View 100°(Typ)
Contrast Ratio
400 : 1
Brightness
White 250 cd/ m²
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (8-bit with FRC)
Response Time
Rising Time 5 ms, Decay Time 11 ms
Operating System
Dos, Unix, Linux, OSX, Windows ( XP, 7, 8, Server 2012 R2)
Multi Platform
Support PS/2 and USB
System Cables
VGA + PS/2 x 2 or VGA + USB x 1 cable
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
16W, 10.41W for Panel
Temperature
Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language
USA, UK, German, French, Spanish, Italian, Portuguese,
Dutch, Swiss, Belgium, Swedish, Norwegian, Danish, Japan,
Taiwan, Russian, Hebrew
Certification
CE / FCC, UL / CUL / C-Tick, GOST
Table 1-1. Gemini 15 Specification
