Gemini P-700 Service Manual

5 074-189 2 INTEGRATED CIR-
CUIT TDA7294V
6
7 076-075 1 SILICON TRANSIS-
TORS 2SA1358
8 076-077 SILICON TRANSIS-
TORS OR 2SB631
9 076-074 1 SILICON TRANSIS-
TORS 2SC3421
10 076-076 SILICON TRANSIS-
TORS OR 2SD600
11 076-020 1 SILICON TRANSIS-
TORS 2SA733 (Q)(P)
12 076-023 SILICON TRANSIS-
TORS OR 2SA1015
(GR)(Y)
13
14 086-019 1 BRIDGE RECTIFIER
KBPC804W
15 087-027 2 VU METER
16
17 079-003 11 SILICON DIODE
1N4148
18 079-020 2 ZENER DIODE 1/2W
24V (RD24EB2)
19
20 080-086 1 LED (GREEN) 5φ
21
22 071-202 2 ROTARY VR 10KA
L:15MM
23 081-023 1 SLIDE SWITCH 2P2C
UL
24 081-030 1 SLIDE SWITCH
25 083-099 1 POWER SWITCH
26 001-613 1 DC FAN 24V
(80×80×25mm)
27
28 092-105 1 AC INLET
(IEC+FUSE)
29
30 100-072 2 FUSE 20mm VBS UTE
5A 250V
31 100-063 1 FUSE 20mm VBS UTE
4A 250V
32 100-064 1 FUSE 20mm VBS UTE
2A 250V
33
34 161-160 1 2P RCA JACK
35 161-172 1 4P SPEAKER TERMI-
NAL
36 161-109 4 FUSE CLIP JH-6
37
38 059-239 1 POWER TRANS-
FORMER EI-76×60
39 147-024 2 COIL 1.3µH 1.0φ×9φ×
9 1/2T
40
41 093-370 1 AC CORD SVT AWG
18×3C VW-1 UL
42 093-371 1 AC CORD 220V VDE
43 093-410 1 AC CORD ARGEN-
TINA
44 093-369 1 AC CORD 230V BS
45
46 061-102 2 METAL FILM RESIS-
TORS 2W 8.2Ω
47 060-842 2 CARBON FILM RE-
SISTORS 1/2W 22KΩ
48 060-240 1 CARBON FILM RE-
SISTORS 1/4W 82 Ω
49 060-250 2 CARBON FILM RE-
SISTORS 1/4W 220 Ω
50 060-263 4 CARBON FILM RE-
SISTORS 1/4W 750 Ω
51 060-279 3 CARBON FILM RE-
SISTORS 1/4W 2.2KΩ
52 060-288 13 CARBON FILM RE-
SISTORS 1/4W 5.1KΩ
53 060-293 3 CARBON FILM RE-
SISTORS 1/4W 8.2KΩ
54 060-303 5 CARBON FILM RE-
SISTORS 1/4W 22KΩ
55 060-351 1 CARBON FILM RE-
SISTORS 1/4W 1MΩ
56
57 050-153 2 ELECTROLYTIC
CAPACITORS N.P
10µ/50V
58 050-162 1 ELECTROLYTIC
CAPACITORS
10µ/50V
59 050-121 7 ELECTROLYTIC
CAPACITORS
22µ/50V
