Audio Specifications| frequency response | 20 Hz - 20 KHz +/- 2dB |
|---|---|
| distortion | <0.02% |
| S/N ratio | Better Than 85 dB |
Power| power source | AC 15v 500mA |
|---|---|
| max output | 20 V Peak-to-Peak |
| rec output | 225 mV, 5 KOhm |
Inputs| phono input | 3 mV, 47 KOhm |
|---|---|
| line input | 150 mV, 27 KOhm |
| mic input | 1.5 mV, 1 KOhm Balanced |
Headphone Specifications| headphone impedance | 8 Ohm |
|---|
Weight and Dimensions| unit dimensions | 10” x 3.3” x 12” (254 x 84 x 304 mm) |
|---|---|
| unit weight | 6.5 lbs (2.94 kgs) |
