,167$//$7,21
(YDFXDWLRQXVLQJEDODQFHGIOXH
*HQHUDOLQVWUXFWLRQV
The sealed combustion circuit THR boiler connec-
ted to a vertical or horizontal balanced flue is inde-
pendent of the ventilation conditions in the room
where it is installed. A horizontal balanced flue must
be installed when the wall adjoining the water heater
gives onto the outside in a well ventilated location.
Two concentric tubes supply air to the burner and
evacuate the combustion products. The conduits
can be bent, allowing the system to be adapted to
most installation situations.
The flue terminal cover is specially designed to
withstand wind from all directions as well as rain and
snow.
([DPSOHDVVHPEO\
HORIZONTAL BALANCED FLUE INSTALLATION
VERTICAL BALANCED FLUE INSTALLATION
)LJ
