LED name
Location
Color
LED Behavior
Status Indication
LED List
●●●
●●●
MAIN power
●○○
○○○
Blue
ON
Power On
OFF
Power Off
Ethernet
status
○●○
○○○
Yellow
Steady ON
Ethernet Connected
Blinking
Data Transmission
OFF
No Ethernet action
SIM status
○○●
○○○
Green
Steady ON
SIM Detected
Blinking when
On-hook
PUK / PIN Code
OFF
No SIM Detected
LTE Status LED : Link Status
When CPE is power on, each LED
indicates each link status
LTE 1
○○○
●○○
Red
Steady ON
CINR < 8dB
LTE 2
○○○
●●○
Red/
Yellow
Steady ON
8dB < CINR <
15dB
LTE 3
○○○
●●●
Red/
Yellow/
Green
Steady ON
15dB < CINR
