Genelec 8330 User Manual

12
Post-production facility applications
In certain applications, such as large
post-production studios, subwoofer
placement along the front wall is
not recommended as this places
the subwoofer very far from the
listening position, and the subwoofer
frequency response will not be at.
In these cases, we recommended
locating the subwoofer close to the
main monitor setup along the side
walls. Using two subwoofers, one
along each side wall, may provide an
improved low frequency atness.
1.1 m>
Max
60 cm
Avoid
Avoid
Min 5 cm
110°
60°
+10°
-10°
RS
C
Screen
R
LS
L

Genelec 8330 Specifications

General

Frequency Response	45 Hz - 23 kHz (-6 dB)
Type	Active Studio Monitor
Configuration	2-Way
Crossover Frequency	3 kHz
Amplifier Power	50 W (LF), 50 W (HF)
Driver Dimensions	5 inch (woofer), 0.75 inch (tweeter)
Maximum SPL	104 dB
Weight	5.5 kg
Input Connectors	1 x XLR Analog
Enclosure Type	Reflex
