PARTS LIST – MAIN UNIT
Item Part # Qty Description
1 G93199 1 CRADLE, XL
2 G84021 1 SUPPORT, Engine
3 NSP 1 ENGINE, 6.5 HP XL
4 66365 1 HOUSING, Engine Adapter
5 84141J 1 ASSEMBLY, Rotor
6 83540J 1 ASSEMBLY, Stator
7 65791 1 BEARING
8 96796 1 WASHER, M8 Flat
10 86307 4 SCREW, 6/16-24 x 3/4 HHM
11 47480 1 SCREW, 5/16-24 x 7" Cap
12 84508 2 MOUNT, 45º Vibration
13 52858 8 NUT, M8 Locking
14 83208 1 BRACKET, Muffler
15 DB4986 1 DECAL, Ground
16 66476 2 SCREW, M6 - 1.0 x 12
17 89476 1 GASKET, Exhaust
18 70644 1 SCREW, M8-1.25 x 20 PPHM
19 84346 3 SCREW, M8 x 35 PPHM
20 40976 2 SCREW, M8 - 1.25 x 20
21 83083 1 SCREEN, Spark Arrest
22 83071 1 MUFFLER
23 81917 1 PIN, M4 x 10 Roll
25 66825B 1 CARRIER, Rear Bearing
26 85652 2 MOUNT, Vibration
27 67989 2 NUT, M8 Flange Serrated
30 74908 4 M5-8.0 x 10 Taptite
32 86308 4 BOLT, M6-1.0 x 115 Stator
33 65795 1 RECTIFIER, Battery Charge
34 66849A 1 M5-0.7 x 20 Taptite
35 67022 1 GROMMET, Rubber
36 84132 1 MODULE, Drive
37 66386 1 ASSEMBLY, Brush Holder
38 66849 2 M5-0.7 x 16 Taptite
39 B4871 1 COVER, Bearing Carrier
41 86494 1 SCREW, M6-1.0 x 16mm Wing
Item Part # Qty Description
42 86292 1 HHCS, 10-16 x 3/4" Self Drill
43 77395 4 NUT, M6 Flange Lock
44 83465 4 GROMMET, Tank
46 78831B 4 SCREW, M6-1.0 x 60 (black)
47 80270 1 VALVE, Tank
48 78299 1 BUSHING, Plastic Tank
49 85134 1 GAUGE, Fuel Cap
50 88325 1 TANK, Fuel
51 B84042 1 SHIELD, Heat
52 84687 1 INSULATION, #2 1/4"
53 85000 1 CLIP, Insulation
54 14353621 1 WIRE, Ground
55 23762 1 WASHER, #10 Shakeproof
56 26850 2 WASHER, M6 Shakeproof
60 B4356 1 DECAL, Control Panel
61 92982 1 DECAL, Danger
62 B4357 2 DECAL, Heat Shield
63 93826 1 DECAL, Start Instruction
64 B1432 1 ASSEMBLY, Control Panel
65 20566 1 DECAL, GENERAC 1-800#
66 77816 1 DECAL, Caution Hot Muffler
67 B2153 4 HHCS, 12-14 x 7/8" Self Drill
68 84409 1 SLEEVING, Flexo, HW 1/2" X
.83 ft.
Items Not Illustrated
65787 1 Battery Charge Cable
B4354 1 Owner’s Manual
BB3061 1 Oil, 28 oz.
43483 1 120/240 Volt 20 Amp Plug
37806 1 120 Volt 30 Amp Plug
Optional Accessories Not Included:
84883 Ext. Cord Wrap
84895 Storage Cover
