PARTS LIST — PUMP
Item Part # Qty Description
1 110B2126 1 Cap
2 10887628P 1 Circlip
3 112B2126 1 Snap Ring
4 113B2126 1 Bearing
5 109B2126 1 Pump Body
6 11287628P 1 Oil Cap/Dipstick
7 11187822P 3 Nut
8 11187822P 3 Piston Washer
9 123B2126 3 Piston
10 11687628P 3 Spacer Disc
11 11587628P 3 O-Ring
12 115B2126 3 Piston Pin
13 120B2126 3 Guiding Piston
14 119B2126 3 Con Rod
15 118B2126 1 Complete Rear Cover
16 117B2126 6 Screw
17 116B2126 1 O-Ring
18 12687628P 1 Snap Ring
19 12587628P 1 Bearing
20 149B2126 1 Hollow Shaft
21 155B2327 4 Screw
22 152B2126 1 Grub Screw
23 63281 1 Key, ¼ sq x 2
Service Kits:
Item Part # Qty Description
24 150B2126 1 Gas Engine Flange
25 22237 4 Lckwshr, 3/8
26 23645 4 SHCS, 3/8-16 x 1.25
27 151B2126 1 Bushing
28 12187822P 1 Seal
29 B1554 1 Valve, Thrmal Relief
30 10487628P 2 Plug
31 137B2126 8 Washer
32 10087822P 8 Screw
33 102B2126 6 Plug
34 10187822P 6 O-Ring
35 10287822P 6 Complete Valve
36 10387822P 6 O-Ring
37 11193360P 1 Plug
38 136B2126 1 Head
39 10387628P 2 O-Ring
40 106B2126 3 Support Ring
41 10587822P 3 Gasket
42 108B2126 3 Piston Guide
43 10393360P 3 Gasket
44 10493360P 3 O-Ring
45 131B2126 3 Rear Piston Guide
46 16593360P 3 Seal
A B C D E
500-87628P
Valve Kit
201-B2126
Piston Kit
202-B2126
Oil Seal Kit
203-B2126
Water Seal Kit
204-B2126
Support Ring
Kit
Item Qty. Item Qty. Item Qty. Item Qty. Item Qty.
35
36
6
6
8 3
1
17
46
1
1
3
41
44
3
3
40 3
