Generac Portable Products 3,000 PSI High Pressure Washer
5
IMPORTANT: Read entire owner’s manual before you
attempt to assemble or operate your new pressure washer.
REMOVE PRESSURE
WASHER FROM
CARTON
• Remove the high pressure hose, handle, and parts box
included with pressure washer.
• Slice two corners at the end of carton from top to
bottom so the panel can be folded down flat, then
remove all packing material.
• Roll pressure washer out of carton.
Carton Contents
Items in the carton include:
• Main unit
• High pressure hose
• Handle
• Pump oil dipstick (hanging on pump)
• Accessory box (includes the following):
• (2) bottles of engine oil
• Owner’s registration card
• Safety goggles
• Nozzle cleaning kit
• Bag containing 5 multi–colored quick connect nozzles
• O–Ring maintenance kit
• Owner’s manual
• Engine manual
• Engine warranty card
• Emissions control warranty card
• Spark arrestor screen
• Spray gun with quick connect fitting
• Nozzle extension with quick connect fitting
• Handle hardware, including 4 carriage bolts and
4 flange nuts
If any of the above parts are missing or damaged, call the
pressure washer helpline at 1–800–270–1408.
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged, call the
pressure washer helpline at 1-800-270-1408.
To prepare your pressure washer for operation, you
will need to perform these tasks:
• Fill out and send in the registration card.
• Attach the handle to the main unit.
• Add oil to the engine.
• Add fuel to the fuel tank.
• Connect the high pressure hose to the spray gun and the
pump.
• Connect the water supply to the pump.
• Connect nozzle extension to spray gun.
• Select and install desired nozzle.
Attach Handle to the Pressure
Washer
Use either a 13mm or adjustable wrench to attach the
handle to the pressure washer.
To attach handle to the pressure washer:
• Slowly tip the pressure washer forward and let it gently
rest on the front bumper.
• Align the holes on the handle with the holes on the base.
• Insert the carriage bolts provided to hold the handle in
place (Figure 1).
Figure 1 — Attach Handle to Pressure Washer
