Generac Portable Products 2,500 PSI High Pressure Washer
10
• Move throttle lever to “Fast” position, shown as a
rabbit.
• Position the choke lever to the “Choke” position.
NOTE: For a warm engine, be sure the choke lever is in
the “Run” position.
• Push the On/Off switch to the “On” position.
•F
or electric start, press push-button start switch until
engine cranks and starts. Limit electric start cycles to 5
seconds of cranking per every 30 seconds to prolong life
of starter.
•F
or manual start, pull slowly on recoil handle until you
feel some resistance. Then pull rapidly to start engine.
Return handle slowly. Do Not let it “snap back” against
starter housing.
• If the choke was placed in the “Choke” position to start
the engine, slowly push it to the “Run” position as the
engine warms up enough to run smoothly.
• If the engine fails to start, review instructions given in the
engine owner’s manual.
How to Stop Your Pressure Washer
• Move throttle lever to “Slow” position.
• Push on/off switch to the “Off” position.
• Turn the fuel shut-off valve to the “Off” position.
• Squeeze trigger on the spray gun to relieve
pressure in the hose.
NOTE: A small amount of water will squirt out when you
release the pressure.
Battery Safety
NOTE: Battery is a sealed lead acid battery.
DANGER! If battery case cracks, Do Not permit
smoking, open flame, sparks or any other source of
heat around battery. Wear protective goggles,
rubber apron and rubber gloves when working
around battery. Battery electrolyte fluid is an
extremely caustic sulfuric acid solution that can
cause severe burns. If spill occurs, flush area with
clear water immediately.
How to Use Battery Charger
Use battery charger jack with the provided battery charger
to keep the starting battery charged and ready for use.
Battery charging should be done in a dry location, such as
inside a garage.
• Lift the flap to plug the charger into the unit’s “12V DC
Battery Charger” jack. Plug battery charger into a
120 Volt AC wall receptacle.
• Unplug the charger from the unit and the wall outlet
when pressure washer is being started and while it is in
operation.
• Keep this charger plugged in when pressure washer is
not in use to prolong battery life. The charger has a built
in float equalizer and will not overcharge the battery,
even when plugged in for an extended period of time.
IMPORTANT: See “Battery Maintenance” on page 15 for
additional information.
How to Use the Nozzles
DANGER! Never exchange nozzles without
locking the safety latch on the spray gun.
The quick–connect on the nozzle extension allows you to
switch between four different nozzles. The nozzles vary the
spray pattern, as shown in Figure 13.
To change nozzles:
• Engage the safety latch on the spray gun.
Use to apply
detergent
0°
15°
Red
40°
WhiteBlack
25°
Figure 13 - Nozzle Spray Patterns
Yellow
To Next Page
