ITEM PART NO. QTY. DESCRIPTION
1 0D6822 1 TRAY, ENCLOSURE
2 0D6942 1 PANEL, ENCLOSURE SIDE
3 0D6939 1 PANEL, REAR DIVIDER
4 0D6943 1 PANEL, ENCLOSURE ROOF
5 0D6941 1 PANEL, ENCLOSURE BACK
0D6941A 1 PANEL, ENCLOSURE BACK, EXTERNAL
PORT (04709 ONLY)
6 0D6940 1 PANEL, FRONT DIVIDER
0D6940A 1 PANEL, FRONT DIVIDER, EXTERNAL
PORT (04709 ONLY)
7 0D6945 1 COMPARTMENT, AIR INTAKE
8 0G7329 1 PANEL, ENCLOSURE DOOR
9 0D8254 1 SHIELD, MUFFLER
10 0C5644 2 SLIDE LATCH, FLUSH
11 0D7513 1 PUMP, FUEL
12 087769 1 FILTER, FUEL
13 0D7613 1 FUEL LINE, FILTER TO PUMP
14 0D7614 1 FUEL LINE, PUMP TO CARB
15 048031C 2 CLAMP HOSE BAND ¼”
16 047411 2 SCREW HHC M6-1.0 X 16
17 022473 2 WASHER FLAT ¼”
18 023484S 1 BUSHING, 1.09” SNAP
19 022097 2 WASHER LOCK M6-1/4”
20 086729 1 CONTACTOR, STARTER
21 0D3700 24 NUT FLANGE M6-1.0 NYLOK
22 022129 2 WASHER LOCK M8-5/16”
23 022259 2 NUT HEX 5/16”-18
24 075763A 2 BOOT BATTERY CABLE
25 0D7293 1 PANEL AIR BOX COVER
26 064113 1 SCREW, M6-1.00 x 20mm WING
27 0C7561 1 BOLT CARR 3/8”-16 X 1”
28 0A4456 1 3/8” SPECIAL L/WASHER
30 049813 2 NUT HEX M6 X 1.0
ITEM PART NO. QTY. DESCRIPTION
31 022237 1 WASHER LOCK 3/8”
32 022131 2 WASHER FLAT 3/8-M10”
33 0C5443 1 BLOCK, TERMINAL BATTERY POST
34 0C7423 1 STUD 3/8”-16 X 2”-1/4” BRASS
35 029451 2.1’ TAPE FOAM 1/8” x ½”
36 074908 4 SCREW HHTT M5-0.8 X 10
37 0D8717 1 CUSTOMER CONNECTION HARNESS
38 0D9020 1 FOAM, AIR OUT COMPARTMENT SIDE
39 0742600144 1 CABLE, STARTER
40 0E0724 1 ASSEMBLY OIL DRAIN
41 0G4933 18 SCREW SWT 1/4-20 X 5/8 W/W
42 0742600143 1 CABLE, BATTERY CONNECTION
43 0D8595 1 MOUNT, FUEL FILTER SUPPORT
44 0D8627 2 FOAM, AIR INTAKE COMPARTMENT
45 0D8628 1 FOAM, ROOF AIR OUT COMPARTMENT
46 0D8628A 1 FOAM, BACK COMPARTMENT
47 0D8691 1 FOAM, DOOR PANEL
48 0D7176 4 WASHER SELF LOCKING 1”
49 0A2115 1 WASHER NYLON .250”
50 0D9282 1 HARDWARE CLOTH COMPARTMENT
AIR OUT
51 023484E 1 BUSHING, 0.50” SNAP
52 0F9176 8.5” HOSE, 1/4” ID
53 0E0014 1 BOX, MUFFLER TAIL PIPE
54 0E0017 1 GASKET, MUFFLER TAIL PIPE BOX
55 0C7968 4 NUT HEX JAM 3/8”-16 BRASS
56 0E0393 1 ASSEMBLY, CAP & DIPSTICK
57 0D8981 1 FILTER GASKET
58 029451A 8.75’ FOAM TAPE 1/16” X ½”
59 0D8628B 1 FOAM, FRONT AIR OUT
COMPARTMENT
60 0G7366 1 LOGO. QP
61 0A9973 2 RIVET, POP
Section 6 — Exploded Views and Parts Lists
Recreational Vehicle Generator
Enclosure – Drawing No. 0D8352-K
