19
High Pressure Washer
Generac 2250PSI High Pressure Washer
1 A1040D 1 HOSE, 4-1/2 Chemical Clear
2 A1041 1 FILTER, Chemical Hose
3 70453 1 TAG, Warning Oil
4 97178 2 KNOB, Handle 1/4 - 20 PW
5 31669 2 BOLT, 1/4 - 20 x 1-3/4 Carriage
6 21424 1 CONNECTOR, Garden Hose
7 99583 8 NUT, Flange Lock 5/16-28
8 B1982 1 BUMPER
9 97054 1 TAG, Pres. Adjust
10 B1288 1 TAG, PW Breather Cap
11 B2718 1 CLAMP, Hose 7/16" Dia.
13 32713 1 SCREW, Taptite #10 - 32 x 5/8" Lg
12 97566 1 TAG, Nozzle
14 45771 8 NUT, M8 - 1.25 Hex
15 22129 8 LOCKWASHER, M8
16 21217 2 MOUNT, Rubber Shock
17 B1236F NOZZLE, Replacement 1.25 mm
18 97100 1 CAP, H.P. Adaptor
19 97098 1 CAP, Garden Hose Inlet
20 B2043 7 BOLT, 5/16 - 18 x 1-3/4" Carriage
21 N/A 1 ASSEMBLY, Pump
(see pump exploded view)
22 B1827 1 ENGINE
23 B1983 1 HANDLE
24 B1631A 1 BILLBOARD, Plastic
25 B1932 1 DECAL, Instructions
26 B1981 2 SUPPORT, Handle
27 B2192 1 DECAL, Generac
28 B1760 2 ASSEMBLY, 10" Tire & Wheel
29 75402 2 PUSHNUT, .50 Dia.
30 AB1770 1 BASE
31 52858 2 NUT, M8 1.25 Locking
32 42909 2 HHCS, M8 1.25 x 30
33 50190 2 WASHER, M8 Flat
34 27007 2 MOUNT, Donut Type Vibration
35 20566 1 DECAL, Generac #1-800
36 B2150 1 HOOK , Gun
37 B2146 1 DECAL, Logo
38 52857 2 NUT, M6 1.0 Locking
39 20707 1 BRACKET, Pump Support
40 21216 2 MOUNT, Rubber Shock
41 38750 2 HHCS, M6 1.0 x 30
42 B1969 1 HOSE, High Pressure
43 87815 1 GOGGLES, Saftey
44 B1867F 1 WAND
45 B1861 1 GUN, High Pressure
46 B2203 1 KIT, Handle Fastening
47 B2163 1 KIT, Cleaning
48 B1460 2 CAP, Vinyl (black)
49 B2168 1 HANGER, Hose, Gun, Jug
65 B2516 1 CAP, Vinyl (black)
66 95441 1 SPACER, Engine Pilot (not
shown)
Item Part # Qty Description
Item Part # Qty Description
