ITEM PART # QTY. DESCRIPTION
85 78608A 1 Air Box Cover
86 90695A 1 Blower Housing
87 89739 1 Lower Wrapper
88 66476 9 M6 X 12 HHCS
89 A2799 1 Recoil Assembly
90 A2842 1 Recoil Cup
91 78651C 1 Backplate
92 59636 1 #4 X 3.37 Long
93 86296 1 Governor Rod
94 88905 1 Extension Spring
95 89477 1 Spring Clip
96 89478 1 Snap Button
97 40976 1 SHCS M8—1.25 X 20
98 90192 1 Carb Wear Washer
99 92059 1 Stepper Motor
— 21 —
GGeenneerraacc GGNN--119900//222200 EEnnggiinnee
EEXXPPLLOODDEEDD VVIIEEWW —— SSTTEEPPPPEERR MMOOTTOORR,, FFLLYYWWHHEEEELL,, RREECCOOIILL SSTTAARRTTEERR
ITEM PART # QTY. DESCRIPTION
55 83512 2 M8 X 15 Taptite
78 82774 1 Woodruff Key
79A SRV77182T 1 191 Flywheel
79B SRV77182E 1 220 Flywheel
80 83312 1 Conical Washer
81 81810 1 M16 Hex Nut
82 92984 1 Top Wrapper
83 45756 4 M6 X 10 Taptite
84 78609 2 Cover Bolts
