1 026812 2 ELBOW 90D 3/4 NPT
2 075580 1 FLANGE FUEL INLET
3 0F6364A 1 FUEL RGLTR 1.5L REWORK
4 039253 4 SCREW HHC M8-1.25 X 20 G8.8
5 022145 2 WASHER FLAT 5/16 ZINC
6 022129 6 WASHER LOCK M8-5/16
7 045771 2 NUT HEX M8-1.25 G8 YEL CHR
8 * 0F1570 1 BODY CARBURETOR ASSEMBLY
9 032552 1 BARBED EL 90 5/16 X 1/8 NPT
10 029032 1 HOSE 9/32 ID
11 025424 1 NIPPLE PIPE 3/4 NPT X 6
12 0F0397 1 HOSE CRANKCASE BREATHER
13 0A5547 1 COVER AIR CLEANER
14 048031C 4 CLAMP HOSE BAND 1/4
15 0D1509 1 DECAL INLET PRESSURE
16 * 0E0591 1 ADAPTER CARB. TO AIR CLNR
17 059402 1 FILTER ELEMENT
18 037561 1 NUT WING 1/4-20 NYLK
19 0E1028C 1 ASSY CARBURETOR 1.5L C1 CPL
20 059401 1 CARBURETOR GASKET
21 * 091526 4 SCREW PPHM M5-0.8 X 12 ZNC
22 * 049226 4 WASHER LOCK M5
23 026915 2 NIPPLE CLOSE 3/4 X 1.375
24 062522 1 STUD TH 1/4-20 X 3 G2 ZNC FULL
25 022127 1 NUT HEX 1/4-20 STEEL
26 022259 2 NUT HEX 5/16-18 STEEL
27 ** 050279 1 DECAL FUEL INLET NG
050280 1 DECAL FUEL INLET LPG
28 0A6125 2 STUD 5/16-18 X 1.25 F THR
29 0F6155 1 HARNESS FUEL JUMPER SINGLE REG
30 * 0E1104 1 GASKET AIR CLEANER ADAPTER
31 * 0E0668 1 O-RING 2-028 1.38 X 1.50 X .06
32 * 0E0590 1 VENTURI 18MM
33 * 0C5133 1 O-RING 29.82 X 2.62
34 * 0E0665 1 SCREW THROTTLE PIN STOP
35 * 0E1108 1 THROTTLE ARM REWORK
36 * 033138 1 SCREW HHM #10-32 X 5/8
37 * 022152 1 WASHER LOCK #10
38 * 0E0645 1 LEVER THROTTLE STOP
39 * 034339 1 BARBED EL 90 3/8 NPT X 5/8
40 059194 1 HOSE 5/8 ID LPG & NG (24” LG)
41 057823 2 CLAMP HOSE #10 .56 - 1.06
42 040173 2 CLAMP HOSE #5.5 .62-.62
43 * 089617 1 BARBED STR 1/4 NPT X 1/4 MALE
44 030340 1 HOSE 1/4 ID SAE 30R7
45 0A7040 1 BRACKET-RAD HOSE
* INCLUDED IN ITEM 19 (CARBURETOR ASSY )
NOTES:
1.
REGULATOR (I/N 3) AS SHOWN IN ILLUSTRATION IS SET UP FOR
NATURAL GAS APPLICATION.
2.
TO CONFIGURE REGULATOR FOR LP VAPOR, SWITCH HOSE BARB,
HOSE CLAMP (I/N 41) AND HOSE (I/N 40) FROM “OUT-1” TO “OUT-2”.
REPLACE PIPE PLUG FROM “OUT-2” TO “OUT-1”. USE PIPE SEALANT
ON HOSE BARB AND PIPE PLUG. MAKE SURE TO KEEP PORTS FREE
FROM DEBRIS DURING RECONFIGURATION PROCESS.
3.** FOR LP VAPOR APPLICATION SUBSTITUE LPG FUEL INLET DECAL P/N
050280 FOR NG FUEL INLET DECAL P/N 050279 (ITEM 27).
4 . WHEN SWITCHING FUEL TYPES, THE PROPER DIP SWITCH SITTINGS
MUST BE MADE TO THE CONTROL PANEL. SEE OWNERS MANUAL, FUEL
SECTION FOR MORE DETAILS.
