Generac Power Systems 37kW NG - Page 33

Generac
®
Power Systems, Inc. 31
ITEM PART NO. QTY. DESCRIPTION
1 0E8418 1 DUCT INTAKE MID AL
2 0E8414 1 DUCT DISCHARGE RH AL
3 0E8413 1 DUCT DISCHARGE LH AL
4 0C2454 62 SCREW TH-FRM M6-1 X 16 N WA Z/JS
5 0E7807 1 BAFFLE REAR BOTTOM
6 0E5902 1 POST CORNER LH REAR HSB AL
7 0E5903 1 POST CORNER RH REAR HSB AL
8 0E8387 1 BAFFLE REAR TOP
9 0E5912 2 DOOR SIDE HSB AL
10 0E5911 1 SUPPORT RH SIDE HSB AL
11 089961 2 FOAM STRIP 3/4" WIDE X 3/16" THK (40" LG)
12 0A2115 4 WASHER NYLON .257
13 0E8404 1 BRACKET STIFFENER RH FRONT
14 0D2538A 1 HINGE LIFT OFF TYPE B KNUCKLE
15 0D2538 1 HINGE LIFT OFF TYPE B PIN
16 043116 8 SCREW HHC M6-1.0 X 12 G8.8
17 022097 12 WASHER LOCK M6-1/4
18 022473 12 WASHER FLAT 1/4-M6 ZINC
19 0E7570 2 GAS SPRING
20 0E7571 4 BALL STUD GAS SPRING MOUNT
21 070015 4 NUT HEX 5/16-18 LOCK
22 0E7662 4 SCREW WING M6-1.00 X 25
23 0D2537A 1 HINGE LIFT OFF TYPE A KNUCKLE
24 0D2537 1 HINGE LIFT OFF TYPE A PIN
25 0D2023 2 TRIM VINYL SELF GRIPPING (91" LG)
26 0E7869 2 BRACKET STIFFENING BACK
27 0E8001 1 MUFFLER BOX
28 0E5913 1 ROOF HSB AL
29 0E8798 1 BRACE, FRONT TOP
30 0D3037A 1 LATCH 1/4 TURN NONLOCKING
31 0C7781 2 PAWL DOOR HSB
32 0E5910 1 SUPPORT LH SIDE HSB AL
33 0E8052 1 MUFFLER BOX TOP
34 0D3037 1 LATCH QUARTER TURN LOCKING
35 0E5900 1 POST CORNER LH FRONT HSB AL
36 0E5901 1 POST CORNER RH FRONT HSB AL
37 0E8799 1 BRACE, FRONT BOTTOM
38 0E8415 1 DUCT DISCHARGE MID AL
39 026850 4 WASHER SHAKEPROOF EXT 1/4 STL
40 0912970063 2 ASSY GRD WIRE 99HSB
41 0912970064 2 ASSEMBLY,BASE-DOOR GROUND WIRE
42 049813 2 NUT HEX M6 X 1.0 G8 YEL CHR
43 0E8416 1 DUCT INTAKE LH AL
44 0E8417 1 DUCT INTAKE RH AL
45 0E8665 1 BRACKET STIFFENER LH FRONT
46 0D2023 1 TRIM VINYL SELF GRIPPING (165.5"LG)
50 * 0E8442 1 KIT INSULATION 3.9L HSB
51 0E7829A 1 AI ROOF PANEL 1
52 0E7829B 2 AI DOOR PANEL
53 0E7829P 4 AI CORNER POST PANEL 1
54 0E7829R 2 AI CORNER POST PANEL 2
55 0E7829S 1 AI SUPPORT LH PANEL
56 0E7829T 1 AI SUPPORT RH PANEL
57 0E7829N 2 AI ROOF PANEL 2
58 078115 8 WASHER SELF LOCKING DOME
* ALL ITEMS NOTATED WITH "AI" ARE COMPONENTS OF 0E8442
Section 8 - Exploded Views and Parts
QUIETSOURCE
™ 40kW Liquid-cooled Generators
Enclosure — Drawing No. 0E8800-B
