ITEM PART NO. QTY. DESCRIPTION
1 0D7825A 1 RADIATOR COPPER BRASS
2 0D7174C 1 VENTURI,3.9L CRYSLR HSB 22"FAN
3 0E7640 1 RADIATOR SUPPORT L/H SIDE
4 0E7924 1 HOSE LOWER RADIATOR
5 0F2853 1 HOSE, RADIATOR UPPER, 3.9L
6 0D8252 1 FAN GUARD, TOP
7 0D8251 1 FAN GUARD, BOTTOM
8 0E0726 1 BRACKET, WATER BOTTLE 1.5L MIT
9 076749 1 TANK COOLANT RECOVERY
10 035685 4 CLAMP HOSE #28 1.32-2.25
13 069860C 1 HOSE OIL DRAIN ASSY 21"
14 058443 17 SCREW CRIMPTITE 1/4-20 X 5/8
15 0C2454 5 SCREW TH-FRM M6-1X16 N WA Z/JS
16 052250 2 TAPE FOAM 1 X 1 (27"LG)
17 048031C 1 CLAMP HOSE BAND 1/4
18 029032 1 HOSE 9/32 ID (30" LG)
19 0A2111 1 SCREW SWAGE 10-32 X 5/16 Z/YC
20 0E7640A 1 RADIATOR SUPPORT R/H SIDE
21 035461 1 BARBED STR 1/4NPT X 3/8
22 065852 1 SPRING CLIP HOLDER .37-.62
23 051756 4 SCREW HHC M10-1.5 X 20 G8.8
24 022131 8 WASHER FLAT 3/8-M10 ZINC
25 046526 4 WASHER LOCK M10
26 045772 4 NUT HEX M10-1.5 G8 YEL CHR
Section 8 - Exploded Views and Parts
QUIETSOURCE
™
40kW Liquid-cooled Generators
Radiator — Drawing No. 0E8102-E
Generac
®
Power Systems, Inc. 37
