Generac Power Systems 37kW NG - Page 44

ITEM PART NO. QTY. DESCRIPTION
1 0E8616 1 MUFFLER 7" X 9" X 21" 2.5" IN &
OUT
2 0F1081 1 WYE, PIPE 3.9L CHRYSLER
3 0F1087 1 PIPE R/H SIDE 3.9L CHRYSLER
4 0E8026 1 PIPE L/H EXHAUST MANIFOLD
5 0E5914 1 BRACKET MUFFLER 30" LG
6 0E8702 1 PIPE MUFFLER INLET
7 0E8727 1 PIPE MUFFLER OUT
8 036797 3 BOLT U 5/16-18 X 2.25
9 039253 2 SCREW HHC M8-1.25 X 20 G8.8
10 022145 6 WASHER FLAT 5/16-M8 ZINC
11 022129 9 WASHER LOCK M8-5/16
12 045771 3 NUT HEX M8-1.25 G8 YEL CHR
ITEM PART NO. QTY. DESCRIPTION
13 0C2454 4 SCREW TH-FRM M6-1 X 16 N WA
Z/JS
14 052860 4 NUT TOP LOCK FL M12-1.75
15 052891 4 SCREW HHC M12-1.75 X 80 G8.8
16 0E8816 2 FLANGE EXHAUST 2" PIPE
17 051769 4 WASHER LOCK M12
18 0E0170 1 BLANKET EXHAUST 800MM
19 049808 8 WASHER FLAT M12
20 024114 6 NUT HEX 5/16-24 STEEL
21 080762 2 BOLT U 3/8-16 X 2.62
22 0E8726 2 STRAP MUFFLER
23 039288 1 SCREW HHC M8-1.25 X 55 G8.8
24 0E0170A 1 EXHAUST BLANKET 988MM
T
O
EXHA
UST
MANIF
O
L
D
14
19
1
5
1
9
17
4
11
8
2
0
9
1
0
1
0
2
3
22
21
1
21
3
1
8
11
8
2
8
11
2
0
1
3
6
2
0
22
7
11
1
0
12
1
5
1
3
1
0
CO
MPARTMEN
T
T
O
5
1
9
1
1
12
1
9
17
14
24
T
O
EXHA
UST
MANIF
O
L
D
1
6
42 Generac
®
Power Systems, Inc.
Section 8 - Exploded Views and Parts
QUIETSOURCE
™ 40kW Liquid-cooled Generators
Muffler — Drawing No. 0E8068-F
