4000XL Extended Life Generator
7
6. Remove existing hardware from vibration mounts with
13mm wrench. Use same hardware to attach mounting leg.
7. Remove temporary blocks.
8. Center handle bracket on generator frame at control
panel end of cradle.
9. Attach handle bracket with two cap screws and two hex
nuts. Use two 13 mm wrenches to tighten hardware.
10. Check that all fasteners are tight and tires are inflated
between 15-40 PSI.
BEFORE STARTING
ENGINE
Add Engine Oil and Fuel
• Place generator on a level surface.
• Refer to engine owner’s manual and follow oil and fuel
recommendations and instructions.
NOTE: Check oil often during engine break–in. Refer to
engine owner’s manual for recommendations.
NOTE: The generator assembly rotates on a prelubricated
and sealed ball bearing that requires no additional
lubrication for the life of the bearing.
CAUTION
• Refer to engine manual for oil and fuel fill information.
• Damage to equipment resulting from failure to follow this
instruction will void warranty.
Any attempt to crank or start the engine before it has
been properly filled with the recommended oil will result
in equipment failure.
