Section 9 — Exploded Views and Parts Lists
Air-cooled Generators
Enclosure – Drawing No. 0F9431-B
SHEET METAL PAINT/MATERIAL CODE LEGEND
The following exploded views contain part numbers of various sheet metal components. Only the base part number is listed. When ordering sheet metal, the correct
color and material information must be included as a suffi x at the end of the part number as shown below.
Material Color Example: Desc. Part No. Material Color Order As"
S = Steel N = Tan Roof 0F6522 S = Steel N = Tan 0F6522SN
A = Aluminum G = Gray Door 0F6555 A = Aluminum G = Gray 0F6555AG
B = Black Divider 0F6558 S = Steel B = Black 0F6558SB
