63
Section 9 — Exploded Views and Parts Lists
Air-cooled Generators
10, 13, and 16kW, V-twin Generators – Drawing No. 0F9423-C
ITEM PART NO. QTY. DESCRIPTION
1 0F8186 1 ADATOR, ENGINE
2 0F6694 1 STATOR (16KW)
0F5538 1 STATOR (13KW)
0F7548 1 STATOR (10KW)
3 0F9795 1 ROTOR (16KW)
0F5539 1 ROTOR (13KW)
0F7549 1 ROTOR (10KW)
4 0F7774 1 CARRIER, REAR BEARING
5 0E9579 1 FAN, 12” CURVED BLADE
0F8998 1 FAN, 12” CURVED BLADE (10KW)
6 0F6591 1 MUFFLER
7 0F8078 1 TAIL PIPE, MUFFLER
8 0F7797 1 FLEX BASE
0F8141 1 FLEX BASE (10KW)
9 056482 1 BEARING
10 0C3168 3 5/16 SPECIAL LOCK WASHER
11 0D1838 1 BOLT, IHHCS 3/8”-24 X 15.50”
12 0D1846 4 BOLT, IHHCS M8-1.25 X 345mm
13 0C7038 1 BRACKET, ALTERNATOR MOUNTING
14 0F9396 1 DUCT, ALTERNATOR AIR
15 0D2559 1 GASKET, ALTERNATOR AIR DUCT
16 0C7038A 1 BRACKET, ENGINE MOUNTING
0F4179 1 PLATE, MOUNTING ENG 530HSB
17 0C7758 4 RUBBER MOUNT
18 0388050AD0 1 CABLE, #6 48” BLACK BATTERY
19 0C2417A 1 EARTH STRAP 3/8 X 3/8
20 0F6528 1 EXHAUST FLEX
21 066386 1 ASSEMBLY BRUSH HOLDER
22 029451 2.6 FT TAPE ELEC UL FOAM 1/8 X 1/2
23 049451 1 WASHER FLAT .406ID X 1.62OD
24 022237 5 WASHER LOCK 3/8
25 022511 4 SCREW HHC 3/8 X 16 X 1-1/4
26 022131 4 WASHER FLAT 3/8 ZINC
27 051731 4 SCREW HHC M8-1.25 X 50
28 022145 18 WASHER FLAT 5/16 ZINC
29 049820 4 NUT LOCK HEX M8-1.25 NYL INSERT
30 0G0676 2 SCREW THTT M6-1.0 X 10
31 022129 18 WASHER LOCK M8-5/16
32 022259 8 NUT LOCK HEX 5/16-18
33 059637 2 SCREW TAPTITE 3/8-16 X ¾
ITEM PART NO. QTY. DESCRIPTION
34 0D4662 3 SCREW 5/16-18 X 3/4”
35 0F7065 3 FT HOSE RES ½ LP GAS
36 048031M 4 HOSE CLAMP ¾” I.D.
38 0G0414 1 PLATE, “HOT”
39 0D5823 3 U-BOLT 5/16”-18 X 1.62” WITH SADDLE
40 0E9369 2 GASKET, EXHAUST PORT (10KW)
0C4138 2 GASKET, EXHAUST PORT
41 040173 2 CLAMP HOSE #5.5 0.62”-0.62” (10KW)
42 074995 1.44 FT HOSE ¼ ID LPG 350PSI UL21 (10KW)
43 066849 2 SCREW HHTT M5-0.8 X 16
44 0F7799 1 EXHAUST MANIFOLD
0F8115 1 EXHAUST MANIFOLD (10KW)
45 0F7796 1 FLEX COVER
0F8204 1 FLEX COVER (10KW)
46 0F9385 1 FLEX COVER EXTENSION (10KW)
47 090388 13 SCREW TAPTITE M6-1.0 X 12
48 045771 4 NUT HEX M8-1.25
49 039253 2 SCREW HHC M8-1.25 X 20
50 0F0710 5 RIVET POP 0.125” X 0.337” (10KW)
0F0710 2 RIVET POP 0.125” X 0.337”
51 0F8079 1 BRACKET MUFFLER ACCESS
52 0F9273 1 SOLENOID, 6 VOLTS DC (10KW)
53 0E9592 2 SCREW PPHM $4-40 X 3/8 SEMS (10KW)
54 0E9588 1 LINKAGE, CHOKE (10KW)
55 077091 1 COTTER PIN (10KW)
56 0E9581 1 AIR CLEANER GTH530 HSB (10KW)
57 0E9594 3 SCREW PPPH HI-LO #14-15 X ½ (10KW)
58 0E9590 1 ASSEMBLY, CHOKE SHAFT (10KW)
59 0E9542 1 VALVE, CHOKE (10KW)
60 0D1683 2 SCREW PFHM M3-0.5 X 5 (10KW)
61 077075 1 BOOT, CHOKE SOLENOID (10KW)
62 0E9595 2 SCREW PPPH HI-LO #6/1/2 W/ #5HD
(10KW)
63 0E9589 1 CHOKE HSG (10KW)
64 0E9591 1 SPRING-CHOKE RETURN (10KW)
65 0E9549 1 HOSE, INTAKE GTH530 HSB (10KW)
66 035685 1 CLAMP HOSE #28 1.32-2.25
67 099502 2 CLAMP HOSE #24 B1.06-2.00
68 0C8565 4 SCREW SHC M8-1.25 X 18 G8.8
