51
SECTION 12: LUBRICATION
Figure 12.13 — Low Oil Indicator
Figure 12.14 — Low Oil Switch With Optional Oil Filter
Figure 12.15 — Low Oil Switch Without Optional Oil Filter
TORQUE SPECIFICATION
OIL FILTER ADAPTER BOLT
TORQUE = 9 foot-pounds or 108 inch-pounds
TORQUE SPECIFICATION
LOW OIL SWITCH
TORQUE = 9 foot-pounds or 108 inch-pounds
LOW OIL SWITCH
LOW OIL SWITCH
