SECTION 4: GOVERNOR CONTROLS AND GOVERNOR
Figure 4-8. Dynamic Governor Adjustment
(Vertical Shaft)
SPEED
CONTROL
LEVER
ALLEN
WRENCH
Figure 4-9. Dynamic Governor Adjustment
(Horizontal Shaft)
HIGH
SPEED
SCREW
Figure 4-10. Dynamic Governor Adjustment
(Horizontal Shaft)
4-4
