Generac Power Systems GTH990 User Manual

6-7
SECTION 6: ELECTRIC STARTER
Figure 6-13. Typical 12 Volt Wiring Diagram
BATTERY
CABLE
SUPPLIED
BY
CUSTOMER
12V
SP
IC
LOP
SM
SOLENOID
CHARGING SYSTEM
REGULATOR VOLTAGE
BATTERY +
STATOR
SWITCH AND CABLE
SUPPLIED BY
CUSTOMER
KEY:
SUPPLIED BY CUSTOMER
SW - SWITCH, START/STOP
LOP - SWITCH, LOW OIL PRESSURE
SP - SPARK PLUG SM - STARTER MOTOR
IC - IGNITION COIL
SUPPLIED BY CUSTOMER
WHITE WHITE
AC OUTPUT AC OUTPUT
DC OUTPUT
FS
FS - FUEL SHUTOFF SOLENOID
CONNECT TO IGNITION GROUND WIRE TO GROUND IGNITION ON LOW OIL PRESSURE. CONNECT TO GROUND SIDE OF A LIGHT OR BUZZER TO GROUND THE CIRCUIT AND TURN THE LIGHT OR BUZZER ON WHEN THERE IS LOW OIL PRESSURE.
TO GROUND
IGNITION
SUPPLY 12V TO CRANK ENGINE
SUPPLY 12V TO ALLOW FUEL FLOW
IC
SP
SUPPLIED BY
30 AMP
FUSE
CUSTOMER
BLACK
AC AC
B+
RED
