29
ITEM PART NO. QTY. DESCRIPTION
1 0E7331 1 WELDMENT MTG BASE 3.9L CRYSLR
2 052860 4 NUT FLANGED HEX M12-1.75
3 052251 4 DAMPENER VIBRATION 40 BLUE
4 052257 4 SPACER .49 X .62 X 1.87 PWDR/ZNC
5 052252 4 DAMPENER VIBRATION
6 052259 4 WASHER FLAT M12
7 052891 4 SCREW HHC M12-1.75 X 80 G8.8
8 0536210214 1 ASSY WIRE 15.0"
9 074906 1 SCREW HHTT M6-1.0 X 20 BP
10 047411 1 SCREW HHC M6-1.0 X 16 BP
11 055414 1 LUG SLDLSS #2-#8 X 17/64 CU
12 026850 2 WASHER SHAKEPROOF EXT 1/4 STL
13 022097 1 WASHER LOCK M6-1/4
14 022473 1 WASHER FLAT M6-1/4 ZINC
15 049813 1 NUT HEX M6 -1.0 G8 YEL CHR
16 0A1694 4 1-1/2" BUTTON PLUG
18 025507 3 WASHER SHAKEPROOF EXT 7/16 STL
19 0E7359 2 ENGINE MOUNT (3.9L CHRYSLER)
20 027482 2 WASHER SHAKEPROOF EXT 5/16 STL
21 022129 1 WASHER LOCK M8-5/16
22 045771 1 NUT HEX M8-1.25 G8 YEL CHR
23* 051756 1 SCREW HHC M10-1.5 X 20 G8.8
24* 046526 1 WASHER LOCK M10
25* 022131 1 WASHER FLAT 3/8-M10 ZINC
26* 055934M 1 CLAMP VINYL .75 X .343 Z
27 049820 2 NUT HEX LOCK M8-1.25 NY INS
28 059473 1 HOLD DOWN BATTERY
29 061902 1 HOLD DOWN BATTERY
30 058665 REF. BATT 12VDC 90-AH 27F (NOT INCLUDED)
31 038804D 1 CABLE BATT RED #4 X 20.00
32 038805J 1 CABLE BATT BLK #1 X 30.00
33 021991 1 EARTH STRAP
34 036833 6 SCREW HHC 3/8-16 X 1 G8
35 022237 6 WASHER LOCK 3/8
36 022131 6 WASHER FLAT 3/8 ZINC
37 075763 1 BOOT BATTERY CABLE
38 050331 1 BATTERY POST COVWER (BLACK)
39 050331A 1 BATTERY POST COVWER (RED)
40 0A4010 2 SCREW HHC M8-1.25 X 60 G8.8 FT
41 052858 2 NUT TOP LOCK FL M8-1.25
42 065852 1 SPRING CLIP HOLDER .37-.62
43 045764 1 SCREW HHTT M4-0.7 X 8 BP
* NOT SHOWN-USED TO HOLD DOWN I/N 32.
Section 7 - Exploded Views and Parts
40kW Liquid-cooled Generators
Mounting Base — Drawing No. 0E8084-B
