Number Default Function Name Function Description
103 CHCK V PHS ROT Detected voltage phase rotation as not being A-B-C
104 CHCK C PHS ROT Detected current phase rotation as not being A-B-C and not matching voltage
105 FAULT RLY ACTIVE Audible alarm/warning signal is active.
106 USR CONFIG 106 GenLink controlled: GenLink front panel radio button selected
107 INT EXERCISE ACT Internal Exercise is active – includes QuietTest®
108 CHECK FOR ILC Indicates the ILC is not running
109 USR CONFIG 109 Available for ILC use
110 USR CONFIG 110 Available for ILC use
111 USR CONFIG 111 Available for ILC use
112 USR CONFIG 112 Available for ILC use
113 USR CONFIG 113 Available for ILC use
114 USR CONFIG 114 Available for ILC use
115 USR CONFIG 115 Available for ILC use
116 USR CONFIG 116 Available for ILC use
117 USR CONFIG 117 Available for ILC use
118 USR CONFIG 118 Available for ILC use
119 USR CONFIG 119 Available for ILC use
120 USR CONFIG 120 Available for ILC use
45
Appendix B
H-100 Control Panel Technical Manual
