Operation
32 Owner’s Manual for MLT3060M-K Light Tower
7. See Figure 3-10. Check the wheel lugs. Tighten or
replace any lugs that are loose or missing. If a tire
has been removed for axle service or replaced,
tighten the lugs, in the order shown, to the
following specifications:
Figure 3-10. Tightening Wheel Lugs
a. Start all lug nuts by hand.
b. First pass: tighten to 20-25 ft-lbs (27-33 Nm).
c. Second pass: tighten to 50-60 ft-lbs (67-81 Nm).
d. Third pass: tighten to 90-120 ft-lbs (122-162 Nm).
NOTE: After the first road use, re-torque the lug nuts in
sequence.
8. Maximum recommended speed for highway towing
is 45 mph (72 km/h). Recommended off-road
towing speed is not to exceed 10 mph (16 km/h) or
less, depending on the terrain.
Tying the Unit Down
When securing the unit for transportation, verify the
equipment being used to fasten the unit is in good
condition and has sufficient strength to hold the unit in
place during transport.
See Figure 3-11. Use the tie-down points (A) as shown.
Figure 3-11. Tie-Down Points
Lifting the Unit
Follow these steps to prepare the unit for lifting:
1. Verify the equipment being used to lift the unit is in
good condition and has sufficient capacity. For
approximate weights, see Specifications.
2. Close and lock all hoods and doors.
3. See Figure 3-12. Stow the mast and lights in the
travel position as shown.
4. Always remain aware of people and objects around
the unit while preparing, maneuvering, and lifting
the unit.
• When lifting the unit, attach any slings, chains or
hooks directly to the central lift point (A).
• Use the forklift pockets (B) with care. Lift only from
the side. Avoid approaching the unit at an angle,
as this can permanently damage the forklift
pockets, tires, or cabinet. Verify the forklift tines
are clear of any obstructions before lifting.
Figure 3-12. Lift Points
