Generac Power Systems MC4000

Generac Portable Products MC4000 Generator
17
Item Part # Qty Description
1 93199 1 CRADLE, XL
2 84021 1 SUPPORT, Engine
3 NSP 1 ENGINE
4 66365 1 HOUSING, Engine Adapter
5 84141 1 ASSEMBLY, Rotor
6 83540 1 ASSEMBLY, Stator
7 65791 1 BEARING
8 67451 1 WASHER, M8 Flat
10 86307 4 HHMS, 5/16-24 x 3/4
11 47480 1 HHCS, 5/16-24 x 7"
12 84508 2 MOUNT, Vibration 45°
14 83208 1 BRACKET, Muffler
15 B4986 1 DECAL, Ground
16 66476 2 HHMS, LW M6 1.00 x 12
17 89476 1 GASKET, Exhaust
18 70644 1 PPHMS, M8 1.25 x 20
19 84346 3 PPHMS, M8 x 35
20 40976 2 SHCS, M8 1.25 x 20
21 83083 1 SCREEN, Spark Arrest
22 83071 1 MUFFLER
23 81917 1 PIN, Roll M4 x 10
25 66825B 1 CARRIER, Rear Bearing
26 85652 2 MOUNT, Vibration
27 67989 10 NUT, M8 Flanged Serrated
30 74908 4 TAPTITE, M5-0.8 x 10
32 86308 4 BOLT, M6 - 1.0 x 115
33 65795 1 RECTIFIER, Battery Charge
34 66849A 1 TAPTITE, M5 0.8 x 20
35 67022 1 GROMMET, Rubber
36 84132 1 ASSMBLY, Drive Module Pwr
Reg.
37 66386 1 ASSEMBLY, Brush Holder
38 66849 2 TAPTITE, M5 0.8 x 16
39 67025 1 COVER, Bearing Carrier
Item Part # Qty Description
41 86494 1 SCREW, M6 -1.0 x 16 Wing
42 86292 5 HHCS, 10 - 16 x Self Driller
43 77395 4 NUT, M6 Flange Lock
44 83465 4 GROMMET, Tank
46 78831B 4 HHMS, M6 1.0 x 60 (blk)
47 80270 1 VALVE, Tank
48 78299 1 BUSHING, Plastic Tank
49 85134 1 CAP, Fuel
50 88325 1 TANK, Fuel
51 84042 1 SHIELD, Heat
52 84687 1 INSULATION, #2-1/4" Thick
53 85000 1 CLIP, Insulation
54 14353621 1 WIRE, Ground
55 23762 1 WASHER, Shakeproof #10
56 26850 2 WASHER, M6 Shakeproof
61 92982 1 DECAL, Danger
62 92782 2 DECAL, Heat Shield
67 93221 2 DECAL, Cradle
68 93826 1 DECAL, Start Instructions
69 84409 1 SLEEVING, Flexo 1/2" X .83 ft.
Parts Not Illustrated:
37806 120 Volt AC 30 Amp Plug
43483 120/240 Volt AC 20 Amp Plug
65787 Battery Charge Cable
72347 Spark Plug
78601 Air Filter
84882 Spark Plug Wrench
99060 Owner’s Manual
NSP Engine Owner’s Manual
Optional Accessories Not Included:
84883 Cord Wrap
84895 Storage Cover
PARTS LIST – MAIN UNIT
