Usethisreceptacletooperate240VoltAC,60Hz,single
phaseloadsrequiringupto8,000watts(8.0kW)ofpower.
Theoutletisprotectedbya35Amppush-to-resetcircuit
breaker.
120/240 Volt AC, 30 Amp, Locking
Receptacle
Use a NEMA LI4-30 plug with this receptacle.Connect a
4-wire cord set rated for 250Volt AC loads at 30 Amps (or
greater) (Figure 6).You can usethe same 4-wire cord if you
)lanto run a 120Volt load.
4-Wire Cord Set
i
f
(Neutral)
Y (Hot) | X (Hot)
NEMA L14-30 /_ Ground (Green)
This receptacle powers 1201240Volt AC, 60 Hz, single
phase loads requiring up to 3,600 watts of power at
30 Amps for 120Volts;7,200 watts of power (7.2 kW) at
30 Amps for 240Volts.The outlet isprotected bya 30 Amp
push-to-reset circuit breaker.
120 Volt AC, 30 Amp Locking
Receptacle
Use a NEMA L5-30 plug with this receptacle. Connect a
3-wire cord set rated for 125Volt AC loads at 30 Amps to
the plug (Figure 7).
_ire Cord Set NEMA L5-30
Neutral
120V
Hot
Ground (Green)
Usethis receptacle to operate 120VoltAC, 60 Hz, single
phaseloads requiring up to 3,600 watts (3.6 kW) of power
at 30Amps.The outlet is protected by a 30Amp
push-to-reset circuit breaker.
120 Volt AC, 20 Amp, Duplex
Receptacle
Eachreceptacle (Figure 8) is protected against overload by
a 20 Amp push-to-reset circuit breaker.
Use each receptacle to operate 120Volt AC, single-phase,
60 Hz electrical loads requiring up to 2,400 watts (2.4 kW)
at 20Amps of current. Use cord sets that are rated for
125Volt AC loads at 20Amps (or greater).
i
10
