Owner’s Manual for Portable Generator 5
Section 2 General Information and Setup
Figure 2-1. Features and Controls
Generator Components
Figure 2-2. Control Panel (49 State)
Figure 2-3. Unit Identification Label
000480
000478
8
14
16
15
17
18
7
13
9
11
6
12
19
10
1 120/240 Volt AC, 30 Amp Locking
Receptacle (NEMA L14-30R)
2 Circuit Breakers (AC)
3 Hour Meter
4 Battery Charger Input
5 120 Volt AC, 20 Amp, GFCI Duplex
Receptacle (NEMA 5-20R)
6 Fuel Gauge
7 Roll Over Valve
8 Battery Location
9 Oil Check/Fill
10 Oil Drain
11 Handle
12 Recoil Starter
13 Air Filter
14 PowerDial
15 Fuel Cap
16 Recovery Hose
17 Fuel Tank
18 Muffler
19 Grounding Lug
000488
1 5 3
2
2
4
009117
