1 0F9579 1 RTR-2390-60KD2 CPL
2 0F9578 1 ASSY STR 2390 60AD2 CPL
0F9659 1 ASSY STR 390 60KW 2P 3PH 208V
0F9660 1 ASSY STR 390 60KW 2P 3PH 480V
0G6105 1 STR-2390--60JD2 CPL
3 0C9708 REF INSTR HYPOT TEST (NOT SHOWN)
4 SEE ENGINE EV REF ENGINE ADAPTER
5 SEE ENGINE EV REF FLEXPLATE
6 0F5767B 1 ASSY FLYWHEEL CPL W/40MM FAN B
7 0E5706 1 REAR BEARING CARRIER 390/DRCT
8 0F7874 1 ASSY BRUSH HOLDER 390/HSB
9 0F6125 1 GUARD REAR BEARING CARRIER CPL
10 0F2689 1 RING PRESSURE 390 STATOR CAN
11 023454 1 KEY WOODRUFF #E
12 077043F 1 CONDUIT FLEX 1-1/4" (30” LG)
13 04576100AQ 3 STUD M14-2.0 X 615 G5 ZINC (70KW)
14 052646 4 WASHER FLAT M14
15 043123 6 WASHER LOCK M14
16 051779 4 NUT HEX M14-2.0 G8 YEL CHR
17 0A2601 1 SCREW HHC M16-2.0 X 45 G8.8
18 072879 1 SPACER .69 X 2.75 X .37 ST/ZNC
19 0F3398 4 SCREW SHC M10-1.5 X 16 G10.9
20 046526 4 WASHER LOCK M10
21 0C3993 4 SCREW HHTT M4-0.7 X 25 BP
22 022264 4 WASHER LOCK #8-M4
23 038150 4 WASHER FLAT #8 ZINC
24 * 047248 1 BALL BEARING-45 MM
25 * 070892 1 SLIP RING MACHINED
26 0F7272 6 SCREW 1/4-20 X 5/8" TAPTITE SS
27 0A1633 2 WASHER 390 SAE ALT.
28 0A5580 1 SCREW HHC M14-2.0 X 140 G8.8
29 0D7019 1 SCREW HHC M14-2.0 X 100 G 8.8
* ROTOR REPLACEMENT PARTS
