Section 1 — General Information

Air-cooled 11 kW Generators

1.6 SPECIFICATIONS

1.6.1 GENERATOR

Model 04916-0

Rated Max. Continuous Power Capacity (Watts*) 10,000 NG/11,000 LP

Rated Voltage 120/240

Rated Max. Continuous Load Current (Amps)

120 Volts** 83.3 NG/91.7 LP

240 Volts 41.7 NG/45.8 LP

Main Line Circuit Breaker 45 Amp

Phase 1

Number of Rotor Poles 2

Rated AC Frequency 60 Hz

Power Factor 1

Recommended Air Filter Part # C8127

Battery Requirement Group 26/26R 12 Volts and

at -17.8° C (0° F) 525 Cold-cranking Amperes Minimum

Weight 495 Pounds

Output Sound Level @ 23 ft (7m) at full load 62.2 db (A)

Normal Operating Range -20°F (-28.8°C) to 104°F (40°C)

* Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient temperature, altitude, engine power and condition, etc. Maximum power

decreases about 3.5 percent for each 1,000 feet above sea level; and also will decrease about 1 percent for each 6° C (10° F) above 16° C (60° F) ambient temperature.

** Load current values shown for 120 volts are maximum TOTAL values for two separate circuits. The maximum current in each circuit must not exceed the value stated for 240

volts.

1.6.2 ENGINE

Model 04916-0

Type of Engine GT-990

Number of Cylinders 2

Rated Horsepower 30 @ 3,600 rpm

Displacement 992cc

Cylinder Block Aluminum w/Cast Iron Sleeve

Valve Arrangement Overhead Valves

Ignition System Solid-state w/Magneto

Recommended Spark Plug RC14YC

Spark Plug Gap 0.76 mm (0.030 inch)
