ITEM PART NO. QTY. DESCRIPTION
1 0F0783 1 DUCT INTAKE MID AL 2.5L
2 0F0781 1 DUCT DISCHARGE RH AL 2.5L
3 0F0780 1 DUCT DISCHARGE LH AL 2.5L
4 0C2454 34 SCREW TH-FRM M6-1 X 16 N WA Z/JS
5 0F0779 1 SUPPORT RADIATOR 2.5L AL
6 0E0072AB 1 AI INSULATION SIDE REAR CORNER POST RH
7 0E0072AC 1 AI INSULATION INTAKE DUCT TOP PANEL
8 0E0072AD 1 AI INSULATION LH SIDE REAR CORNER POST PANEL (BOTTOM)
9 0E5912 2 DOOR SIDE HSB AL
10 0F0787 1 SUPPORT RH SIDE AL 2.5L
11 089961 2 FOAM STRIP 3/4" WIDE X 3/16" THK (40" LG)
12 0A2115 4 WASHER NYLON .257
13 0E0072AE 1 AI NSULATION LH SIDE REAR CORNER POST PANEL (TOP)
14 0F0165A 1 HINGE TYPE B W/STUDS, SOCKET
15 0F0165 1 HINGE TYPE B W/STUDS, PIN
17 022097 13 WASHER LOCK M6-1/4
18 022473 13 WASHER FLAT 1/4-M6 ZINC
19 0E7570 2 GAS SPRING
20 0E7571 4 BALL STUD GAS SPRING MOUNT
21 070015 4 NUT HEX 5/16-18 LOCK
22 0E7662 4 SCREW WING M6-1.00 X 25
23 0F0164A 1 HINGE TYPE A W/STUDS, SOCKET
24 0F0164 1 HINGE TYPE A W/STUDS, PIN
25 0D2023 3 GASKET CLIP-ON SELF GRIPPING (84" LG)
26 078115 8 WASHER SELF LOCKING DOME
27 0F2179 1 KIT SAE FOAM 2.5L QUIET SOURCE
28 0F0788 1 ROOF 2.5L FORD AL
29 0E7829B 2 AI DOOR PANEL
30 0D3037A 1 LATCH 1/4 TURN NONLOCKING
31 0C7781 2 PAWL DOOR HSB
32 0F0786 1 SUPPORT LH SIDE AL 2.5L
33 0E0072Q 2 AI INSULATION RAD SUPPORT PANEL
34 0D3037 1 LATCH QUARTER TURN LOCKING
35 0E0072Y 1 AI INSULATION SIDE BRACE PANEL RH
36 0E0072AF 1 AI INSULATION SIDE BRACE PANEL LH
37 0E0072AA 1 AI INSULATION ROOF PANEL
38 0F0782 1 DUCT DISCHARGE MID AL 2.5L
39 026850 4 WASHER SHAKEPROOF EXT 1/4 STL
40 0912970064 2 ASSY WIRE 14AWG 7.5 #0 GRN/YEL
41 0912970063 2 ASSY WIRE 14AWG 7.5 #0 GRN/YEL
42 049813 10 NUT HEX M6 X 1.0 G8 YEL CHR
43 0F0784 1 CORNER POST REAR LH SIDE AL
44 0F0785 1 CORNER POST REAR RH SIDE AL
45 0E8665 1 BRACKET STIFFENER LH FRONT
46 0E8837 1 DOOR BATTERY COMPARTMENT
47 0A3359 1 SCREW BHSC M6-1.0 X 16 SS
48 0E8404 1 BRACKET STIFFENER RH FRONT
* ALL ITEMS NOTATED WITH "AI" ARE COMPONENTS OF 0F2179
Section 8 - Exploded Views and Parts Lists
Liquid-cooled 15, 20 and 25 kW Generators
Enclosure — Drawing No. 0F1645-H
To Next Page
