ITEM PART NO. QTY. DESCRIPTION
1 0F0790 1 TOP, CONTROL PANEL
2 0F0789 1 BACK & BOTTOM, CONTROL PANEL
3 0F0791 1 PANEL, FRONT 2.5L CONTROL PNL
4 0E9704 1 ASSY PCB HSB CONTROLLER 2.5L
5 067680 1 ASSY VOLTAGE REGULATOR 60HZ
6 0E6875A 2 RELAY, 12VDC C FORM W/DIODE
7 0C3910 1 XFMR 240/16V 1VA&56VA
8 048468 1 CIRCT BRK 8 X 1 ETA 46-500-P
9 0D5070A 1 ASSY PCB 2A 12V UL BATT CHRGR
10 057073 1 JUNCTION BLOCK 3/8-16
11 040213 2 PCB SUPPORT SNAP-IN 1/4"
12 0C2265 18 SCREW PHTT M4-0.7 X 12 ZYC
13 029673 1 DIO BRIDGE 25A 600V
14 0F0793 1 BRACKET, CB SIEMENS BQ
15 0E7890 1 BRKT CB MTG BACK
16 0D5541* 1 CB 0070A 2P 240V S BQ2 LL
0D5544** 1 CB 0100A 2P 240V S BQ2 LL
17 0F1264 1 ADPTR,LH SIDE WICKMAN 178.6192
18 0F1263 1 ADPTR,RH SIDE WICKMAN 178.6191
19 0F1262 2 HOLDER, FUSE WICKMANN 178.6150
20 0E7403A 1 FUSE ATO TYPE 5 AMP (TAN)
21 0E7403C 1 FUSE, ATO TYPE 15 AMP (BLUE)
22 0E2514 1 FITTING CONDUIT STR 1-1/2"
23 020911 2 SCREW PPHM M5-0.8 X 30 ZINC
24 023897 4 WASHER FLAT #10 ZINC
25 022152 2 WASHER LOCK #10
26 051716 2 NUT HEX M5-0.8 G8 YEL CHR
27 082573 1 SWITCH ROC DPST 125V SPD
28 0E4494 1 SWITCH ROC DPDT ON-OFF-ON
29 0C4167 REF. BLOCK TERM 20A 14 X 6 X 1100V
30 0C2699 4 SCREW PHTT #6-32 X 3/8 ZYC
31 0C2212 1 SCREW PHTT M4-0.7 X 16 ZYC
32 047411 4 SCREW HHC M6-1.0 X 16 G8.8
33 022097 4 WASHER LOCK M6-1/4
34 022473 4 WASHER FLAT 1/4-M6 ZINC
35 0E7358 4 SCREW PPPH HI-LO #4-24 X 3/8
36 064733 2 RES MTG BRACKET
37 0F0798A 1 HARNESS, C-PNL 2.5L QS 15&20KW (NOT SHOWN)
38 0E6881 REF SOCKET, RELAY
39 048352 1 RES 5R 5% 25W
40 0C1127 1 DECAL AVR COVER
41 0C1229 1 DECAL WARNING ELECTRICAL SHOCK
42 0F2632 1 DECAL TERMINAL BLOCK
43 0F2629 1 DECAL CONTROL HSB
44 0E7193 1 DECAL, WARNINGS HSB
45 0F6146 1 HANG TAG 2 WIRE START (NOT SHOWN)
* 15KW
** 20KW
Section 8 - Exploded Views and Parts Lists
Liquid-cooled 15, 20 and 25 kW Generators
Control Panel (15kW and 20kW) — Drawing No. 0F2267-D
