ITEM PART NO. QTY. DESCRIPTION
1 0E8456 1 BRACKET FUEL REGULATOR
2 075580 1 FLANGE FUEL INLET
3 0E9967 1 ASSY FUEL REG 2.5L FRD N/G-L/P
4 039253 4 SCREW HHC M8-1.25 X 20 G8.8
5 022145 2 WASHER FLAT 5/16 ZINC
6 022129 6 WASHER LOCK M8-5/16
7 045771 2 NUT HEX M8-1.25 G8 YEL CHR
8 * 0F1570 1 BODY CARBURETOR ASSEMBLY
9 0A6344 1 BARBED EL 90 1/8 NPT X 3/8
10 0F3994 REF. PCV VALVE 2.5L FORD
11 0E1056 1 FUEL HOSE ASSM. NAT. GAS/L.P.V.
12 0F0397 1 HOSE CRANKCASE BREATHER
13 0A5547 1 COVER AIR CLEANER
14 048031C 2 CLAMP HOSE BAND 1/4
15 0D1509 1 DECAL INLET PRESSURE
16 * 0E0591 1 ADAPTER CARB. TO AIR CLNR
17 059402 1 FILTER ELEMENT
18 037561 1 NUT WING 1/4-20 NYLK
19 0E1028A 1 CARBURETOR ASSY. 2.5L FORD
20 059401 1 CARBURETOR GASKET
21 * 091526 4 SCREW PPHM M5-0.8 X 12 ZNC
22 * 049226 4 WASHER LOCK M5
23 026307 1 ELBOW 90D STREET 3/4
24 062522 1 STUD TH 1/4-20 X 3 G2 ZNC FULL
25 022127 1 NUT HEX 1/4-20 STEEL
26 022259 2 NUT HEX 5/16-18 STEEL
27 050279 1 DECAL FUEL INLET NG
28 0A6125 2 STUD 5/16-18 X 1.25 F THR
29 0C2454 3 SCREW TH-FRM M6-1 X 16 N WA Z/JS
30* 0E1104 1 GASKET, AIR CLEANER ADAPTER
31* 0E0668 1 O-RING 2-028 1.38 X 1.50 X .06
32* 0E0590A 1 VENTURI 20MM
33* 0C5133 1 0-RING 29.82 X 2.62
34* 0E0665 1 SCREW THROTTLE PIN STOP
35* 0E1108 1 THROTTLE ARM REWORK
36* 033138 1 SCREW HHM #10-32 X 5/8
37* 022152 1 WASHER LOCK #10
38* 0E0645 1 LEVER,THROTTLE STOP
39* 034339 1 BARBED EL 90 3/8 NPT X 5/8
40 059194 1 HOSE 5/8 ID LPG & NG (24" LG)
41 057823 2 CLAMP HOSE #10 .56 - 1.06
42 0F0382 1 HOSE 3/8" 90 DEG 2.5L PVC
* INCLUDED IN ITEM 19 (CARBURETOR ASSY )
Section 8 - Exploded Views and Parts Lists
Liquid-cooled 15, 20 and 25 kW Generators
Fuel System — Drawing No. 0E9980-D
