28 Owner’s Manual for Stationary Diesel Generators

Figure 5-3. Left Side View

Figure 5-4. Front View

NOTE: The 3.4L engine is depicted in the artwork used in this manual. The location and appearance of some

components may vary between engine models.

Fuel Filter/Air Bleed

Battery

Governor

Linkage

Coolant Overflow

Reservoir

Coolant

Drain Hose

Fuel Supply Hose

Fuel Return Hose

Breather Canister

and Filter

Fuel Filler Spout

Fuel Level Gauge

Emergency Vent

Primary Tank

Fuel Tank

Primary Vent

Emergency Vent

Secondary Tank
