Generac Power Systems SE10000 User Manual

Generac Portable Products SE10000 Generator
19
GENERATOR PARTS LIST
Item Part # Qty Description
1 NSP 1 ENGINE, Robin 18HP
2 BB4509 1 SHIELD, Heat
3 A77304 2 SUPPORT, Engine
4 BB4811 1 SHIELD, Heat
5 80270 1 VALVE, Fuel Shut-Off
6 78299 1 BUSHING, Fuel Valve
7 B4325 1 CAP, Fuel Tank
8 38353 6 MOUNTS, Vibration
9 78831B 4 CAPSCREW, M6-1.0 x 60mm
10 B1696 1 TANK, Fuel 10 Gal
11 AB4426 1 CRADLE
12 83465 4 GROMMET, Mounting
14 23152 7 CAPSCREW, 3/8-16 x 3/4"
15 22237 20 WASHER, 3/8" Lock
16 22241 10 NUT, 3/8"-16 Hex
17 22746 4 CAPSCREW, 3/8-16 x 1-3/4"
18 22131 8 WASHER, 3/8" Flat
19 BB5117 1 SHIELD, Heat
20 B4425 1 ASSEMBLY, Control Panel
21 195-53621 1 WIRE ASSEMBLY, Ground
22 38750 1 HHCS, M6 - 1.0 x 30
23 B4502 1 SWITCH, Key Ignition
24 22145 2 WASHER, M8 Flat
25 26850 3 WASHER, M6 Shakeproof
26 20566 1 DECAL, 1-800
27 B4986 1 DECAL, Ground
28 92982 1 DECAL, Danger
29 B4865 1 DECAL, Side Panel
30 B4866 1 DECAL, Control Panel
31 78817 1 DECAL, Data Plate
32 77816 2 DECAL, Caution Hot Muffler
33 B4826 1 DECAL, Start Instructions
34 B4824 1 DECAL, Start - Run - Stop
35 79552 1 DECAL, Overlaminate
36 73054 1 DECAL, Fuel Shut-Off
37 B4268 1 ALTERNATOR, 10KW
38 BB4481 1 GUARD, Muffler
39 20441 4 SCREW, 1/4" x 3/4" Self
Driller
40 B4489 1 BATTERY
Item Part # Qty Description
41 B4627 1 KEY, Ignition Switch
42 AB4682 1 BRACKET, Ignition Switch
43 A96925 1 BRACKET, Battery Tie Down
44 96924 2 J-BOLT, M8 - 1.25
45 193-53621 1 CABLE, Battery Positive
46 194-53621 1 CABLE, Battery Negative
47 52618 2 HHCS, M5 - 0.8 x 12
48 49226 1 WASHER, M5 Lock
49 52856 2 NUT, M5 Flange Lock
50 49820 2 NUT, Nylok M8 - 1.25
51 39253 1 CAPSCREW, M8 - 1.25 x 20
52 NSP SUPPLIED WITH ENGINE
53 45771 1 NUT, M8 - 1.25
54 27482 1 WASHER, 5/16" Shakeproof
55 47411 2 CAPSCREW, M6 - 1.0 X 16
56 22473 2 WASHER, Flat M6
57 B4948 1 CLAMP, Hose
58 55934G 2 CLAMP, Hose
59 22511 4 CAPSCREW, 3/8 x 1-1/4"
60 B4803 1 CONNECTOR, 5-way
61 52618 1 HHCS, M5 - 0.8 x 12
62 B4794 2 GROMMET, Generator Cover
63 B2153 17 SCREW, #12 Self Driller
64 B4988 1 DECAL, Oil Fill
65 52857 1 NUT, Locking M6 - 1.0
66 87680 1 WING NUT, M6 - 1.0
67 23897 2 WASHER, M5 Lock
68 49813 1 NUT Hex M6 - 1.0
Items Not Illustrated:
BB3061 2 SAE 30 Oil
B3518 1 Oil Bottle Funnel
37806 1 125 Volt 30 Amp Plug
43438 1 240 Volt 30 Amp Plug
93568 1 125 Volt 20 Amp Plug
B4472 1 Owners Manual
B4888 1 Generator Reference Card
NA 1 Engine Owners Manual
