EXPLODED VIEW: EV ENCL L2A B-GRP
DRAWING #:0J1936 GROUP F
ITEM PART# QTY. DESCRIPTION
REVISION: J-3773-D Page 3 of 4
DATE: 1/9/13
(1)1 0F07740ST0R 1 BLOCK OFF FRONT OVERHD
2 027529 8 NUT HEX LOCK 1/4-20 NY INS
(1)3 0C33350ST0R 1 DUCT BOTTOM RAW
4 0C3594 8 ASSY M6 HINGE R/H
5 0C3594A 8 ASSY M6 HINGE L/H
6 022097 16 WASHER LOCK M6-1/4
(1)7 0J16010ST0R 8 BRACKET, ROD GUIDE
(1)8 0J15810ST0R 4 DOOR RH SOLID
(1)9 0F07060ST0R 1 DUCT FRONT LH RAW
10 0C2634A 1 ASSY ACCESS COVER
11 022473 16 WASHER FLAT 1/4-M6 ZINC
(1)12 0J20370AL0R 1 ASSY, ROOF B-GRP
(1)13 0F04770ST0R 1 BARRIER DUCT INSIDE FRT RAW
(1)14 0C34000ST0R 2 COVER EXHAUST RAW
15 0C6749 16 SCREW PPHM M4-0.7 X 12 SS
16 022145 4 WASHER FLAT 5/16-M8 ZINC
(1)17 0F07080ST0R 1 DUCT,FRONT PANEL
(1)18 0J11680ST0R 1 BRACE FRONT TOP
(1)19 0H98270ST0R 2 CENTER SUPPORT DOORS B-GRP
20 0A3359 70 SCREW BHSC M6-1.0 X 16 SS
21 022129 4 WASHER LOCK M8-5/16
(1)22 0F01530ST0R 9 SPLITTER RAW
(1)23 0F12060AL0R 1 DUCT FRONT TOP SLOTTED L2A
24 027958 6 WASHER NYLON .260
25 0J0993A 8 ROLLER ROD, T-HANDLE
26 080490 16 WASHER FLAT #8 SS
(1)27 0H98250ST0R 1 CENTER PANEL REAR
(1)28 0J35670ST0R 1 INTAKE OVERHEAD REAR BAFFLE
(1)29 0H98150ST0R 1 CORNER POST RH FRONT
(1)30 0J15800ST0R 4 DOOR LH SOLID
31 0J0992 4 T-HANDLE, 2-POINT DBL DOOR
(1)32 0H98260ST0R 4 BRACE SIDE TOP & BOTTOM
33 0E3257 11 SCREW HWHTF M6-1.0 X 16
34 0C3393 2 SCREW SHOULDER M8-1.25 X 20
35 0C6748 16 NUT HEX LOCK M4-0.7 SS NYL INS
(1)36 0F07620ST0R 2 ANGLE,WATER DEFLECTOR
37 049813 16 NUT HEX M6-1.0 G8 CLEAR ZINC
(1)38 0H98160ST0R 1 CORNER POST RH REAR
(1)39 0F07070ST0R 1 DUCT FRONT RH RAW
(1)40 0H11530ST0R 2 INTAKE, OVERHEAD MODULE SIDE
(1)41 0F12540ST0R 2 END CAP OVERHD MOD SIDE_INST
42 022769 4 WASHER LOCK INT #10
43 066760 1 STRIP SEALANT 1/8 X 1 (NOT SHOWN)
44 0A9881 1 TRIM VINYL SEAL
(1)45 0F00480ST0R 1 INTAKE OVERHEAD MODULE
(1)46 0H98180ST0R 1 CORNER POST LH REAR
47 0C2454 173 SCREW HWHT M6-1 X 16 N WA Z/JS
(1)48 0H98130ST0R 1 CORNER POST LH FRONT
49 042907 4 SCREW HHC M8-1.25 X 16 C8.8
(1)50 0J35660ST0R 1 INTAKE OVERHEAD MODULE REAR
51 0E7222 2 RAIN SHIELD,DOOR JAMB
52 022127 1 NUT HEX 1/4-20 STEEL
53 0C3397 4 SCREW RATCHET BLK NYLON
54 078115B 12 WASHER SELF LOCKING BLK #4-40
To Next Page
