EXPLODED VIEW: EV ENCL L2A B-GRP
DRAWING #:0J1936 GROUP F
ITEM PART# QTY. DESCRIPTION
REVISION: J-3773-D Page 4 of 4
DATE: 1/9/13
70 0K0328AJ 1 INSULATION OVRHD MDL REAR
71 0K0328AK 2 INSULATION OVRHD MDL REAR
72 0K0328AL 1 INSULATION ROOF
73 0K0328AM 1 INSULATION ROOF
74 0K0328AN 1 INSULATION ROOF
75 0K0328AH 4 INSULATION OVRHD MDL SIDE
76 0K0328AP 4 INSULATION OVRHD MDL SIDE
77 0K0328BF 4 INSULATION OVRHD MDL BTM
78 0K0328AQ 2 INSULATION OVRHD MDL SPLITTER
79 0K0328AR 18 INSULATION OVRHD MDL SPLITTER
80 0K0328AT 1 INSULATION OVRHD MDL FRONT
81 0J1765BN 1 INSULATION OVRHD MDL BTM
82 0J1765AV 1 INSULATION REAR CTR PANEL
83 0J1765AU 2 INSULATION REAR CORNER POST
84 0J1765AS 8 INSULATION BTM SIDE BRACE
85 0J1765W 4 INSULATION RH DOOR SOLID
86 0J1765V 4 INSULATION LH DOOR SOLID
87 0J1765AT 2 INSULATION CTR DOOR SPT
88 0J1765BY 2 INSULATION FRONT CORNER POST
89 0J1765BZ 1 INSULATION FRONT CORNER POST
90 0J1765CA 1 INSULATION FRONT CORNER POST
91 0J1765CB 1 INSULATION FRONT CENTER PANEL
92 0J1765AX 1 INSULATION FRONT DUCT LH SIDE
93 0J1765AY 1 INSULATION FRONT DUCT RH SIDE
94 0J1765AW 1 INSULATION FRONT DUCT INSD PNL
95 0J1765BA 1 INSULATION FRONT DUCT BOTTOM
96 0J1765BB 2 INSULATION FRONT DUCT
97 0J1765AZ 1 INSULATION FRONT DUCT CTR PNL
98 0J1765CJ 2 INSULATION FRONT DUCT
NOTES (UNLESS OTHERWISE SPECIFEID):
(1) SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR)
• MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM.
• CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM
FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).
