Generac Power Systems SVP5000 97193 User Manual

Generac Portable Products SVP5000 Generator
15
Item Part # Qty Description
1 NSP 1 ENGINE, B & S 10 H.P.
2 66825C 1 CARRIER, Rear Bearing
3 91825 1 ASSY., Brush & Bridge
Rectifier
4 66365-G 1 HOUSING, Engine Adapter
5 22129 2 WASHER, M8 - 5/16 Lock
6 86307 4 HHMS, 5/16" x 3/4"
7 91844J 1 ASSEMBLY, Rotor
8 65791 1 BEARING
9 96796 1 WASHER, Special
10 47480 1 HHCS, 5/16" - 24 x 7"
11 91859J 1 ASSEMBLY, Stator
12 81917 1 PIN, M4 x 10 Roll
13 86308C 4 HHCS, M6 - 1.0 x 130
14 48031C 2 CLAMP, Hose 1/4"
15 88977 1 SWITCH, Low Oil Shutdown
16 70642 2 MOUNT, Vibration 45 Deg.
17 B4871 1 COVER, Bearing Carrier
18 52858 6 NUT, M8 Locking 1.25 Flange
19 76222 2 PPHMS, M8 1.25 x 40 mm
20 14353621 1 WIRE, Ground
21 82881 3 LOCK WASHER, Internal
22 86292 5 SCREW, #10 Self Drilling
23 38150 6 FLAT WASHER, #8
24 23365 6 LOCK WASHER, No. 8
serrated
25 B4465 1 DECAL, Control Panel
26 B78951A 1 SHIELD, Heat
27 56893 2 SCREW 10 - 24 x 1/2"
Crimptite
28 77374 1 TANK, Plastic 5 Gal.
29 23365 1 WASHER, No. 8 Shakeproof
30 78831B 4 CAPSC, M6 x 60 mm Hx Hd
31 90878 1 CAP, Fuel
32 77395 4 NUT, M6 Flange Lock
33 78299 1 BUSHING, Plastic Tank
34 80270 1 VALVE, Plastic Tank
35 81898 1 PANEL, Control
Item Part # Qty Description
36 81919 1 COVER, Rear Panel
37 68868 1 OUTLET, 120 Volt 30Amp.
Locking Rec.
38 68867 1 OUTLET, 120/240 Locking
Rec.
39 68759 1 OUTLET, 120 Volt 20Amp
Duplex
40 84242 2 GROMMET, R. B. C.
41 25244 2 NUT, 5/16 - 18 Hex
42 74908 4 TAPTITE, M5 0.8 x 10
43 22264 6 LOCK WASHER, #8
44 51715 6 NUT, Hex M4 - 0.7
45 75207A 1 CIRCUIT BREAKER, 30 Amp
46 75207 2 CIRCUIT BREAKER, 20 Amp
47 26850 2 WASHER, Shakeproof 1/4"
48 75475 6 PPHMS, M4 - 0.7 x 10
49 82857 2 MOUNT, Rubber
50 82308 6 SCREW, Self Tapping
51 86494 1 WING SCREW, M6 x 16
53 A91020 1 CRADLE
54 67022 1 GROMMET, Rubber
55 22471 2 NUT, No. 8-32
56 22769 1 WASHER, Shakeproof #10
57 66849 2 SCREW, M5 - 0.8 x 15
58 91842A 1 WIRE, LOS
59 22695 1 6-Pin Connector - Male
60 22694 1 6-Pin Connector
61 32713 1 SCREW, No. 10-32 x 5/8"
62 91841 1 GASKET, LOS
63 83465 4 GROMMET, Mounting Tank
64 B4986 1 DECAL, Ground
65 B2153 4 SCREW, Self Driller #12-14 x
7/8"
Accessories Not Illustrated
37806 120 Volt, 30 Amp Plug
43483 120/240 Volt, 20 Amp Plug
PARTS LIST  GENERATOR
