General AOG54UMAYT User Manual

2005.08.23
- 1 -
INDOOR UNIT
H x W x D(mm)
240 x 1,660 x 700
OUTDOOR UNIT 1,290 x 900 x 330
DIMENSIONS
INDOOR UNIT
GROSS / NET (kg)
62 / 49
OUTDOOR UNIT 121 / 114 125 / 118
WEIGHT
SPECIFICATIONS
TYPE COOLING COOLING & HEATING
INDOOR UNIT ABG54FBAG ABY54FBAG ABG54UBAG ABY54UBAG
OUTDOOR UNIT AOG54FMAYT AOY54FMAYT AOG54UMAYT AOY54UMAYT
COOLING CAPACITY (kW) 14.5
HEATING CAPACITY (kW) ------- 16.5
POWER SOURCE (V) 400
FREQUENCY 3ø 50Hz
RUNNING
COOLING 9.5
CURRENT
(A)
HEATING ------- 9.5
INPUT WATTS (kW)
COOLING 5.16
HEATING -------
5.30
E.E.R. (kW/kW)
COOLING 2.81
HEATING ------- 3.11
MOISTURE REMOVAL ( /hr) 6.0
AIR CIRCULATION (m
3
/hr) 2,200
FAN MOTOR
TYPE
Hermetic type, 2 poles, 3 phase,
Induced by condenser, Scroll
CODE BN65YEAMT
POWER SOURCE (V) 400
TYPE MFA-45DZM
HI-SPEED (r.p.m.) 1,250
INDOOR UNIT
MED-SPEED (r.p.m.) 1,150
LO-SPEED (r.p.m.) 1,000
OUTDOOR
TYPE MFB-30PTT x2
UNIT
HI-SPEED (r.p.m.) 780
ELECTRICAL DATA
COMPRESSOR
FULL CHARGE AMOUNT (R410A)
7.5 m
10 m 3,300 g 3,500 g
20 m
PIPE LENGTH 25 m 3,500 g 3,700 g
30 m 3,700 g 3,900 g
40 m 4,100 g 4,300 g
50 m 4,500g 4,700 g
ADDITIONAL CHARGE 40 g/m
