2005.08.23
- 4 -
REFRIGERANT SYSTEM DIAGRAM
OUTDOOR UNITI NDOOR UNIT
EVAPORATOR
Refrigerant pipe
19.05mm (3/4")
Refrigerant pipe
9.52mm (3/8")
ACCUMULATOR
CONDENSER
STRAINER
STRAINER
CAPPILLARY
TUBE
COMPRESSOR
PRESSURE
CHECK VALVE
HIGH
PRESSURE
SWITCH
Charging
Valve
Charging Valve
OUTDOOR UNIT
INDOOR UNIT
Refrigerant pipe
19.05mm (3/4")
COOL
EVAPORATOR
Refrigerant pipe
9.52mm (3/8")
Charging valve
Charging
Valve
ACCUMULATOR
STRAINER
COMPRESSOR
EXPANSION
VALVE
STRAINER
CONDENSER
STRAINER
4-way
Valve
MUFFLER x 2
PRESSURE
CHECK VALVE
HIGH
PRESSURE
SWITCH
Models : ABG54FBAG / AOG54FMAYT
ABY54FBAG / AOY54FMAYT
Models : ABG54UBAG / AOG54UMAYT
ABY54UBAG/ AOY54UMAY T
