General AOG54UMAYT User Manual

2005.08.23
8Air Filter 9359739005 9359739005 9359739005 9359739005
12 Base Assy 9359680000 9359680000 9359680000 9359680000
34 Capacitor (Fan Motor) 9900270216 9900270216 9900270216 9900270216
56 Sirocco Fan Assy 9359701002 9359701002 9359701002 9359701002
63 Panel (Front) 9359734000 9359734000 9359734000 9359734000
69 Louver 9359719007 9359719007 9359719007 9359719007
74 Intake Grille 9359738008 9359738008 9359738008 9359738008
91 Hinge 9359699002 9359699002 9359699002 9359699002
109 Casing 9359704003 9359704003 9359704003 9359704003
122 Shaft Holder-B 9357921006 9357921006 9357921006 9357921006
126 Motor Fixing Table 9359681007 9359681007 9359681007 9359681007
138 Kit (Separate Wall Sub Assy) 9371366012 9371366012 9371366012 9371366012
---- Evaporator Sub Assy 9360428196 9360428196 9360428196 9360428196
146 Evaporator Assy 9371073040 9371073040 9371073040 9371073040
160 Kit (Drain Pan) Sub Assy 9371368016 9371368016 9371368016 9371368016
164 Fan Motor Assy-IN 9360457004 9360457004 9360457004 9360457004
174 Hanger Bracket 9359742005 9359742005 9359742005 9359742005
181 Hole Cover 9359691006 9359691006 9359691006 9359691006
185-1 Louver Bushing 9357376004 9357376004 9357376004 9357376004
186 Edge Cover 9361049017 9361049017 9361049017 9361049017
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805 313361275805 313361275805
223 Control Box Assy 9359708001 9359708001 9359708001
9359708001
227 Badge 9359735014 9359735021 9359735014 9359735021
228 Insulation (Louver)-R 9359721000 9359721000 9359721000 9359721000
229 Insulation (Louver)-L 9359722007 9359722007 9359722007 9359722007
234 Room Temperature Thermistor 9703299025 9703299025 9703299025 9703299025
---- Pipe Temperature Thermistor 9900022020 9900022020 9900022020 9900022020
---- Thermistor Spring-A 313728262708 313728262708 313728262708 313728262708
236 Controller PCB Assy 9704557254 9704557254 9704557513 9704557513
240 Remote Control Unit 9371190020 9371190020 9371190013 9371190013
240-1 Kit (Panel Pipe-L) Sub Assy 9371362014 9371362014 9371362014 9371362014
240-2 Kit (Panel Pipe-R) Sub Assy 9371363011 9371363011 9371363011 9371363011
253-1 Wire Assy (Connector) 9702321017 9702321017 9702321017 9702321017
253-2 Wire Assy (Connector) 9702322014 9702322014 9702322014 9702322014
253-3 Wire Assembly 9702311018 9702311018 9702311018 9702311018
253-4 Wire Assy (Connector) 9702323011 9702323011 9702323011 9702323011
253-5 Wire Assy (Connector) 9702319014 9702319014 9702319014 9702319014
253-6 Wire Assy (Connector) 9702317010 9702317010 9702317010 9702317010
253-7 Wire Assy (Connector) 9702318017 9702318017 9702318017 9702318017
253-9 Wire Assembly 9704847010 9704847010 --------- ---------
286
Shaft Holder Bracket 9359686002 9359686002 9359686002 9359686002
321 Flap Assy 9359731009 9359731009 9359731009 9359731009
329 Coupling Pipe Assy 9373038184 9373038184 9373038184 9373038184
338-1
Motor Fixture 9359702009 9359702009 9359702009 9359702009
338-2 Motor Fixture-B 9359703006 9359703006 9359703006 9359703006
345-1 Filter Guide-R 9359692003 9359692003 9359692003 9359692003
345-2
Filter Guide-L 9359693000 9359693000 9359693000 9359693000
361 Bushing 9359733003 9359733003 9359733003 9359733003
379 Hinge Plate (Grille) 9359694007 9359694007 9359694007 9359694007
PA R TS LIST
When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
INDOOR UNIT
Ref.
No.
Description
ABY54FBAG ABG54FBAG
Ord.
Q'ty
Part No.
ABY54UBAG ABG54UBAG
ABY54FBAG
ABG54FBAG
ABY54UBAG
ABG54UBAG
- 23 -
