380 Locking Spacer KGLS-6S 313209391403 313209391403 313209391403 313209391403
381-4 Locking Spacer KGPS-6S 0600118075 0600118075 0600118075 0600118075
382 Cover (Decoration)-R 9359744009 9359744009 9359744009 9359744009
383 Cover (Decoration)-L 9359745006 9359745006 9359745006 9359745006
384 Shaft 9359707004 9359707004 9359707004 9359707004
385 Indicator PCB Assy 9702260019 9702260019 9702260019 9702260019
386 Panel-Left Assy 9359685005 9359685005 9359685005 9359685005
387 Panel-Right Assy 9359683001 9359683001 9359683001 9359683001
388 Joint Assy 9359706007 9359706007 9359706007 9359706007
396 Reinforcement Metal 9359697008 9359697008 9359697008 9359697008
403 Shaft Holder Fixture 9359687009 9359687009 9359687009 9359687009
407 Rod (Motor) 9359723004 9359723004 9359723004 9359723004
408 Louver Link 9359726005 9359726005 9359726005 9359726005
424 Sector Gear 9359729006 9359729006 9359729006 9359729006
434 Louver Base 9359718000 9359718000 9359718000 9359718000
435 Louver Spring 9359720003 9359720003 9359720003 9359720003
436 Flap Spring 9359730002 9359730002 9359730002 9359730002
438 Pinion Gear 9359728009 9359728009 9359728009 9359728009
448 Control Box-B 9359713005 9359713005 9359713005 9359713005
472 Control Box-A 9359712008 9359712008 9359712008 9359712008
505 Louver Stopper 9359724001 9359724001 9359724001 9359724001
506 Louver Rod 9359725008 9359725008 9359725008 9359725008
580 Top Cover 9359737001 9359737001 9359737001
9359737001
625 Cord Bushing 9359240006 9359240006 9359240006 9359240006
684 Motor Base 9359727002 9359727002 9359727002 9359727002
735 Distributor Assy 9360455000 9360455000 9360455000 9360455000
743 Remote Control Unit Holder 9305642014 9305642014 9305642014 9305642014
752 Pipe Fixture Metal 9359688006 9359688006 9359688006 9359688006
755 Casing Cover 9359705000 9359705000 9359705000 9359705000
761 Side Cover-R 9359740001 9359740001 9359740001 9359740001
762 Side Cover-L 9359741008 9359741008 9359741008 9359741008
763 Receiver Cover 9359714002 9359714002 9359714002 9359714002
815-1 Terminal-3P 9900203016 9900203016 9900203016 9900203016
868 PCB Holder 9359736004 9359736004 9359736004 9359736004
875 Power Supply PCB Assy 9704561138 9704561138 9704561060 9704561060
876-1 Motor, Step-H 9360479013 9360479013 9360479013 9360479013
876-2 Motor, Step-V 9360307026 9360307026 9360307026 9360307026
982-1 Cord Clamp-A 9359820017 9359820017 9359820017 9359820017
982-2 Cord Clamp-B 9359821014 9359821014 9359821014 9359821014
When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
INDOOR UNIT (Continued)
Ref.
No.
Description
ABY54FBAG ABG54FBAG
Ord.
Q'ty
Part No.
ABY54UBAG ABG54UBAG
ABY54FBAG
ABG54FBAG
ABY54UBAG
ABG54UBAG
- 24 -
